KVM console with KVM switch - 16 ports - USB - US - English (QWERTY) - 17" (17.3" viewable) - rack-mountable - 3840 x 2160 4K @ 60 Hz - 400 cd/m² - 16xHDMI - black - 1U - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | NTI RACKMUX KVM console - 4K - 17" - HDR - TAA Compliant |
| Device Type | KVM console - 17" |
| KVM Switch | USB - 16 ports |
| Keyboard Layout | US - English (QWERTY) |
| Features | Keyboard, touchpad |
| Native Resolution | 4K 3840 x 2160 at 60 Hz |
| Pixel Pitch | 0.0995 mm |
| Brightness | 400 cd/m² |
| Color Support | 16.7 million colors (8-bit) |
| Input Connectors | 16xHDMI |
| Voltage | AC 100-240 V (50/60 Hz) |
| Color | Black |
| Dimensions (WxDxH) | 19 in x 28.3 in x 1.7 in |
| Height (Rack Units) | 1U |
| Weight | 26.01 lbs |
| TAA Compliant | Yes |
| Compliant Standards | RoHS, HDCP 2.2, HDCP 1.4, VESA DDC 2 B, Plug and Play |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Display Type | KVM console / TFT active matrix |
| Diagonal Size | 17" |
| Viewable Size | 17.3" |
| Native Resolution | 4K 3840 x 2160 at 60 Hz |
| Pixel Pitch | 0.0995 mm |
| Brightness | 400 cd/m² |
| Color Support | 16.7 million colors (8-bit) |
| Features | Auto Power Off |
| Color | Black |
| Dimensions (WxDxH) | 19 in x 28.3 in x 1.7 in |
| Height (Rack Units) | 1U |
| Weight | 26.01 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Features | Rugged steel enclosure, powder coated, lockable, numeric pad, LED indicator |
| Included Accessories | Cable management tray, 4 screws, 18 cable ties |
| Cables Included | 1 x DB-9 to RJ-45 adapter ¦ 1 x network cable - 5 ft |
| Rack Mounting Kit | Included |
| MTBF | 22,738 hours |
| Compliant Standards | RoHS, HDCP 2.2, HDCP 1.4, VESA DDC 2 B, Plug and Play |
| TAA Compliant | Yes |
| Power | |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption (Typical) | 51 Watt |
| Software / System Requirements | |
| OS Required | Microsoft Windows 7 / 8 / 10 / 11, Microsoft Windows Server 2008, Microsoft Windows Server 2012, Microsoft Windows Server 2016, Microsoft Windows Server 2019, Microsoft Windows Server 2022, Linux, FreeBSD, Apple macOS 10, Apple macOS 11, Apple macOS 12, Apple macOS 13 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 90% RH (non-condensing) |
| Connectivity | |
| Interfaces | 16 x HDMI ¦ 16 x USB (Type B) ¦ 2 x USB (Type A) ¦ RS-232 |
| KVM | |
| Type | KVM switch - 16 ports |
| Keyboard / Mouse Interface | USB |
| Max Resolution | 3840 x 2160 @ 60 Hz |
| KVM Max Supported Video Bandwidth | 18 Gbps |
| Input | |
| Type | Keyboard, touchpad |
