Document camera - color - 13 MP - 4224 x 3156 - motorized - audio - wireless - HDMI, USB - MJPEG, YUV - with Pilot Air
| Main Specifications | |
|---|---|
| Product Description | HoverCam Orbit Trio - document camera - with Pilot Air |
| Device Type | Document camera |
| Bundled with | Pilot Air |
| Audio | Yes: built-in microphone |
| Dimensions (WxDxH) | 4 in x 11 in x 16 in |
| Weight | 30.4 oz |
| Connectivity Technology | Wireless |
| Camera | Color |
| Optical Zoom | 10 x |
| Max Resolution | 4224 x 3156 |
| Frame Rate (max) | 120 frames per second |
| Video Modes | 4K, 1080p, 720p |
| Optical Sensor Type | BSI-CMOS 13 MP |
| Focal Length Control | Motorized zoom |
| Focus Adjustment | Automatic |
| Lens Iris | F/2.0 |
| Interfaces | HDMI, USB |
| Software Certification | Zoom Certified, Google Meet Certified, Certified for Microsoft Teams, Cisco Webex Certified |
| Cables Included | 5 - USB-C cable - external ¦ 1 - USB-A to USB-B cable - external ¦ 1 - HDMI cable - external |
| Features | Auto Focus, Auto Focus Lock, End-to-End Encryption, Adaptive Sensor Resolution (ASR) technology, built-in 4 LED lights, 180° flip |
| Manufacturer Warranty | 5-year warranty |
| Environmental Parameters (operating) | -13 °F - 161.6 °F |
| General | |
| Device Type | Document camera |
| Audio Support | Yes: built-in microphone |
| Connectivity Technology | Wireless |
| Width | 4 in |
| Depth | 11 in |
| Height | 16 in |
| Weight | 30.4 oz |
| Bundled with | Pilot Air |
| Expansion / Connectivity | |
| Ports | HDMI ¦ USB-C |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Included Accessories | USB hub, remote control, receiver mount |
| Cables Included | 5 x USB-C cable - external ¦ 1 x USB-A to USB-B cable - external ¦ 1 x HDMI cable - external |
| Software Certification | Zoom Certified, Google Meet Certified, Certified for Microsoft Teams, Cisco Webex Certified |
| Compliant Standards | FCC, RoHS |
| Power | |
| Power Device | Power adapter + battery |
| Battery | Lithium ion 9800 mAh (up to 6 hour(s)) |
| Software / System Requirements | |
| Software Included | HoverCam Flex 11, HoverCam Flex (for Mac), HoverCam Flex Android, HoverCam for Chrome |
| OS Required | Apple MacOS, Windows, Google Chrome OS, Android |
| Environmental Parameters | |
| Min Operating Temperature | -13 °F |
| Max Operating Temperature | 161.6 °F |
| Camera | |
| Type | Color |
| Digital Video Format | MJPEG, YUV |
| Max Digital Video Resolution | 4224 x 3156 |
| Video Modes | 4K, 1080p, 720p |
| Digital Zoom | 20 |
| Video Capture | 4224 x 3156 @ 30 fps ¦ 1920 x 1080 @ 60 fps ¦ 1280 x 720 @ 120 fps |
| Features | Auto Focus, Auto Focus Lock, End-to-End Encryption, Adaptive Sensor Resolution (ASR) technology, built-in 4 LED lights, 180° flip |
| Lens Construction | |
| Type | Motorized zoom |
| Optical Zoom | 10 x |
| Lens Iris | F/2.0 |
| Focus Adjustment | Automatic |
| Image Sensor | |
| Type | 13 MP BSI-CMOS |
| Interfaces | |
| Video | HDMI, USB |
