NVR - 100 channels - 250 GB - networked
| Main Specifications | |
|---|---|
| Product Description | ACTi GNR-350 - standalone NVR - 100 channels |
| Device Type | NVR - 100 channels - networked |
| IP Cameras Supported | 100 |
| Frame Rate | 120 fps |
| Compression Format | AVI, H.264, MJPEG, MPEG-4, H.265 |
| Image Resolution | 1920x1200 |
| Hard Drive(s) Supported | Quantity: 6 - total capacity: 24 TB |
| Voltage | 100 - 240 V |
| Dimensions (WxDxH) | 7.5 in x 19.4 in x 16.8 in |
| Manufacturer Warranty | 3 years |
| General | |
| Device Type | NVR |
| Video Channels | 100 |
| IP Cameras Supported | 100 |
| Image Resolution | 1920x1200 |
| Compression Format | AVI, H.264, MJPEG, MPEG-4, H.265 |
| OS Provided | Windows 11 Enterprise |
| Color | Black |
| Warranty | 3 years |
| Networking | |
| Network Interfaces | Ethernet 2.5GBase-T |
| Supported Protocols | ONVIF, DHCP, IPv4, IPv6, TCP, UDP, HTTP, HTTPS, DNS, NTP, RTP, RTSP, SMTP, FTP, ICMP, ARP, Bonjour, UPnP, LDAP, iSCSI |
| Features | Pan, Tilt, Zoom (PTZ) control signals transmission |
| Power | |
| Voltage | 100 - 240 V |
| Power Consumption | 400 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 85% RH (non-condensing) |
| Hard Drive | |
| Quantity Supported | 6 |
| Interface | Serial ATA |
| Supported Max Total Capacity | 24 TB |
| Connections | |
| Video Output Ports | DisplayPort x 1, HDMI x 1 |
| Audio Output Ports | Mini-phone 3.5 mm x 1 |
| Network Port | 2.5GBase-T |
| Other Ports | USB 2.0 x 4, USB 3.0 x 2, USB 3.2 x 3, USB-C x 1 |
| Dimensions & Weight | |
| Width | 7.5 in |
| Depth | 19.4 in |
| Height | 16.8 in |
| Security DVR | |
| Frame Rate (Record) | 120 fps |
| Playback Search | Alarm, event, time |
| Record Events | Scheduled, event, manual |
| Networked | Yes |
| Features | RAID 0 support, RAID 1 support, RAID 5 support, RAID 10 support, motion detection, intrusion detection, object recognition, people counting, temperature detection, traffic monitoring |
| Video Server | |
| CPU | Intel Core i3-14100 |
| HDD | 250 GB |
| RAM | 16 GB |
