Patch cable - RJ-45 (M) to RJ-45 (M) - 0.2 in - STP - CAT 6a - IEEE 802.3af/IEEE 802.3at/IEEE 802.3bt type 3 and type 4 - solid, halogen-free - off-white
| Main Specifications | |
|---|---|
| Product Description | Panduit Pan-Net TX6A patch cable - off-white |
| Type | Patch cable - CAT 6a - IEEE 802.3af/IEEE 802.3at/IEEE 802.3bt type 3 and type 4 |
| Technology | STP |
| Wiring Scheme | T568B |
| Features | Solid, halogen-free, polycarbonate housing plug, modular connector, PoE ready, PoE+ Ready, PoE++ ready |
| Cable Length | 1 m |
| Diameter | 0.2 in |
| Connector | RJ-45 - male |
| Connector (Second End) | RJ-45 - male |
| Color | Off-white |
| Image Color Disclaimer | The displayed product image may be a different color |
| General | |
| Network Cable Type | Patch cable - CAT 6a - IEEE 802.3af/IEEE 802.3at/IEEE 802.3bt type 3 and type 4 |
| Technology | STP |
| Wiring Scheme | T568B |
| Jacket Material | Low Smoke Zero Halogen (LSZH) |
| American Wire Gauge (AWG) | 28 |
| Features | Solid, halogen-free, polycarbonate housing plug, modular connector, PoE ready, PoE+ Ready, PoE++ ready |
| Cable Length | 1 m |
| Diameter | 0.2 in |
| Color | Off-white |
| Image Color Disclaimer | The displayed product image may be a different color |
| Miscellaneous | |
| Compliant Standards | ANSI/TIA-568.2-D Category 6A, ISO 11801 Class Ea, ANSI/TIA-1096-A, IEC 60332-1, IEC 60603-7, IEC 60754-1, IEC 61034-2, RoHS, UL 1863 - up to 500 MHz |
| Environmental Parameters | |
| Min Operating Temperature | 14 °F |
| Max Operating Temperature | 167 °F |
| Connectivity | |
| Connector | RJ-45 - male |
| Connector (Second End) | RJ-45 - male |
