Multifunction printer - color - ink-jet - A4 (8.25 in x 11.7 in) (original) - A4/Legal (media) - up to 55 ppm (copying) - up to 55 ppm (printing) - 600 sheets - 33.6 Kbps - Gigabit LAN, USB host, USB 3.0
| Main Specifications | |
|---|---|
| Product Description | Epson WorkForce Enterprise AM-C550z - multifunction printer - color |
| Device Type | Multifunction printer |
| Fax Type | Super G3 - plain paper |
| Printing Technology | Ink-jet (color) |
| Inkjet Technology | Epson PrecisionCore MicroTFP - 4-ink |
| Monthly Duty Cycle (max) | 384000 pages |
| Recommended Monthly Volume | 4500 - 30000 pages |
| Max Copying Speed | Up to 55 ppm (mono) / up to 55 ppm (color) |
| Max Copying Resolution | Up to 600 x 600 dpi (mono) / up to 600 x 600 dpi (color) |
| Max Copying Resolution Class | Up to 600 x 600 dpi (mono) / up to 600 x 600 dpi (color) |
| Max Printing Speed | Up to 55 ppm (mono) / up to 55 ppm (color) |
| Max Printing Resolution | Up to 600 x 2400 dpi (mono) / up to 600 x 2400 dpi (color) |
| Max Printing Resolution Class | Up to 600 x 2400 dpi (mono) / up to 600 x 2400 dpi (color) |
| Max Fax Transmission Speed | 33.6 Kbps |
| Scanning | 600 x 600 dpi |
| Display | 10.1" |
| Original Size | A4 (8.25 in x 11.7 in) (max) |
| Original Type | Sheets |
| Document Feeder Capacity | 100 sheets |
| Media Size | Legal (8.5 in x 14 in), A4 (8.25 in x 11.7 in) (max) |
| Media Type | Envelopes, plain paper |
| Standard Media Capacity | 600 sheets |
| Max Media Capacity | 2100 sheets |
| Bypass Feeder Capacity | 100 sheets |
| Output Trays Capacity | 300 sheets |
| Automatic Duplexing | Yes (copying) Yes (printing) Yes (scanning) |
| Connection Availability | Yes |
| Interface | Gigabit LAN, USB host, USB 3.0 |
| AirPrint Enabled | Yes |
| Office Machine Features | Scan to e-mail, scan to FTP, scan to USB host, scan to network folder |
| Dimensions (WxDxH) | 28.4 in x 19.3 in x 31.3 in |
| Weight | 163.14 lbs |
| Environmental Standards | EPEAT Silver |
| General | |
| Device Type | Multifunction printer |
| Fax Type | Plain paper |
| Printing Technology | Ink-jet - color |
| Monthly Duty Cycle (max) | 384000 pages |
| Recommended Monthly Volume | 4500 - 30000 pages |
| Display Diagonal Size | 10.1" |
| Display Color Support | Color |
| Display Features | Touch screen |
| Connection Availability | Yes |
| Interface | Gigabit LAN, USB host, USB 3.0 |
| AirPrint Enabled | Yes |
| Office Machine Features | Scan to e-mail, scan to FTP, scan to USB host, scan to network folder |
| Memory | |
| Standard Memory | 8 GB |
| Hard Disk Drive | 320 GB |
| Power | |
| Power Consumption Operational | 115 watt |
| Power Consumption Standby | 45 watt |
| Power Consumption Sleep | 0.9 watt |
| Environmental Parameters | |
| Sound Emission | 56.2 dBA (operating) |
| Connections | |
| Interfaces | 1 x USB 3.0 ¦ 1 x USB host ¦ 1 x Gigabit LAN |
| Security Protocols & Features | WEP, WPA-PSK, AES, WPA2-Enterprise, WPA3-SAE |
| Operating System Support | MS Windows Server 2008 R2, MS Windows Server 2012 x64 Edition, MS Windows Server 2012 R2, MS Windows Server 2008 (32/64-bits), MS Windows 7 (32/64 bits), Windows 8 (32/64-bits), Windows 8.1 (32/64-bits), Windows 10 (32/64-bits), MS Windows Server 2016, Apple Mac OS X 10.11 or later, MS Windows Server 2019, Windows 11, MS Windows Server 2022, Apple Mac OS X 11 or later |
| Software Included | Drivers & utilities, Epson Document Capture Pro, EPSON Scan 2, Epson Device Admin (EDA) |
| Copying | |
| Max Copying Speed | Up to 55 ppm (mono) / up to 55 ppm (color) |
| Max Copying Resolution | Up to 600 x 600 dpi (mono) / up to 600 x 600 dpi (color) |
| Max Copying Resolution Class | Up to 600 x 600 dpi (mono) / up to 600 x 600 dpi (color) |
| Max Document Enlargement | 400% |
| Max Document Reduction | 25% |
| Maximum Copies | 9999 |
| Automatic Duplexing | Yes |
| Printing | |
| Inkjet Technology | Epson PrecisionCore MicroTFP |
| Nozzle Configuration | 5784 nozzles (black), 5784 nozzles per color |
| Max Printing Resolution | Up to 600 x 2400 dpi (mono) / up to 600 x 2400 dpi (color) |
| Max Printing Resolution Class | Up to 600 x 2400 dpi (mono) / up to 600 x 2400 dpi (color) |
| Max Printing Speed | Up to 55 ppm (mono) / up to 55 ppm (color) |
| Ink Cartridge Configuration | 4 cartridges (1 each: cyan, magenta, yellow, black) |
| Color | 4-ink |
| Minimum Ink Droplet Size | 3.8 pl |
| Printer Drivers / Emulations | PCL 5e, PCL 6, PostScript 3, PCL 5c, EPSON ESC/P-R, EPSON ESC/Page |
| Image Enhancement Technology | Variable Sized Droplet Technology |
| Ink Type | Epson DURABrite Pro inks |
| Automatic Duplexing | Yes |
| First Print Out Time B/W | 5.5 sec |
| First Print Out Time Color | 5.5 sec |
| Scanning | |
| Scan Element | CIS |
| Automatic Duplexing | Yes |
| Optical Resolution | 600 x 600 dpi |
| Fax Machine | |
| Compatibility | Super G3 |
| Max Transmission Speed | 33.6 Kbps |
| Total Memory Capacity | Up to 550 pages |
| PC Faxing | Yes |
| Fax Machine Features | |
| Error Correction Mode (ECM) | Yes |
| Speed Dialing | 2000 station(s) |
| Broadcast Transmission | Yes |
| Remote Fax Retrieval (Polling) | Yes |
| Features | Automatic redialing, color faxing, fax preview, memory reception, address book |
| Document & Media Handling | |
| Max Original Size | A4 (8.25 in x 11.7 in) |
| Original Type | Sheets |
| Document Feeder Capacity | 100 sheets |
| Max Media Size | A4/Legal |
| Min Media Weight | 52 g/m² |
| Max Media Weight | 250 g/m² |
| Supported Media Type | Envelopes, plain paper |
| Supported Media Sizes | Letter A Size (8.5 in x 11 in), Legal (8.5 in x 14 in), Executive (7.25 in x 10.5 in), A4 (8.25 in x 11.7 in), A5 (5.83 in x 8.25 in), B5 (6.93 in x 9.83 in), A6 (4.13 in x 5.83 in), 3.95 in x 5.83 in, B6 (4.92 in x 6.93 in), 5.5 in x 8.25 in |
| Supported Envelope Sizes | US No 10 (4.1 in x 9.5 in), International DL (4.33 in x 8.66 in), International C6 (4.5 in x 6.38 in), International C5 (6.38 in x 9 in), International C4 (9 in x 12.75 in) |
| Standard Media Capacity | 600 sheets |
| Max Media Capacity | 2100 sheets |
| Bypass Feeder Capacity | 100 sheets |
| Output Trays Capacity | 300 sheets |
| Document & Media Handling Details | ADF - 100 sheets ¦ Multi-purpose tray - 100 sheets - Legal (8.5 in x 14 in) weight: 52 g/m² - 250 g/m² ¦ Input tray - 500 sheets - Legal (8.5 in x 14 in) weight: 52 g/m² - 160 g/m² ¦ Output tray - 300 sheets |
| Speed Details | Printing: up to 55 ppm - B/W (ISO/IEC 24734) ¦ Printing: up to 55 ppm - color (ISO/IEC 24734) ¦ Printing: up to 55 ppm (A4) - B/W duplex (ISO/IEC 24734) ¦ Printing: up to 55 ppm (A4) - color duplex (ISO/IEC 24734) ¦ Copying: up to 55 ppm - B/W (ISO/IEC 24735) ¦ Copying: up to 55 ppm - color (ISO/IEC 24735) ¦ Scanning: up to 50 ipm - B/W (ISO/IEC 17991) ¦ Scanning: up to 50 ipm - color (ISO/IEC 17991) ¦ Scanning: up to 100 ipm - B/W duplex (ISO/IEC 17991) ¦ Scanning: up to 100 ipm - color duplex (ISO/IEC 17991) |
| Dimensions & Weight | |
| Width | 28.4 in |
| Depth | 19.3 in |
| Height | 31.3 in |
| Weight | 163.14 lbs |
| Environmental Standards | |
| EPEAT Compliant | EPEAT Silver |
