75" Diagonal Class LED-backlit LCD display - education / business - with touchscreen (multi touch) - 4K UHD (2160p) 3840 x 2160 - Direct LED - black
| Main Specifications | |
|---|---|
| Product Description | LG CreateBoard Core 75TR3BQ-B 75" LED-backlit LCD display - 4K - for education / business |
| Product Type | LED-backlit LCD flat panel display with touchscreen (multi touch) |
| Diagonal Class | 75" |
| Commercial Use | Yes - education / business |
| Color | Black |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| Video Interface | HDMI |
| HDMI Ports Qty | 2 ports |
| Connectivity | LAN |
| PC Interface | USB-C |
| Technology | VA |
| LCD Backlight Technology | Direct LED |
| Image Aspect Ratio | 16:9 |
| TV Tuner | No tuner |
| Commercial Features | Open Pluggable Standard (OPS) support, conformal coating, Local Key Operation, LG CreateBoard Share |
| Picture Enhancements | 72% Color Gamut NTSC |
| Speaker System | 2 speakers |
| USB | 5 ports |
| Included Accessories | Remote control |
| Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 167 Watt |
| Dimensions (WxDxH) - without stand | 67.4 in x 3.9 in x 40.2 in |
| Weight | 94.36 lbs |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Power Consumption Operational | 167 Watt |
| Diagonal Class | 75" |
| Commercial Use | Yes - education / business |
| Combined With | Touchscreen (multi touch) |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Sensors | Auto brightness sensor |
| Video Interface | HDMI |
| HDMI Ports Qty | 2 ports |
| PC Interface | USB-C |
| Modes | Landscape mode |
| Picture Enhancements | 72% Color Gamut NTSC |
| Protection | Tempered glass protection, shatter-resistant, protection glass |
| Dimensions | Without stand |
| Width | 67.4 in |
| Depth | 3.9 in |
| Height | 40.2 in |
| Weight | 94.36 lbs |
| Enclosure Color | Black |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Compliant Standards | CEC, ERP, FCC |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Heat Generation Details | Cabinet - max - 1228 BTU/h ¦ Cabinet - typical - 433 BTU/h |
| Features | Smart energy saving |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% |
| Display | |
| LCD Display Technology | VA |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Image Aspect Ratio | 16:9 |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| LCD Backlight Technology | Direct LED |
| Coating | Anti-reflection, 25% haze |
| Image Contrast Ratio | 5000:1 |
| Brightness | 350 cd/m² |
| Viewing Angle | 178° |
| Viewing Angle (Vertical) | 178° |
| Touchpoints Qty | 40 |
| Response Time | 6.5 ms |
| Display Menu Language | Multilingual |
| Backlight Life | 50,000 hour(s) |
| Commercial Features | Open Pluggable Standard (OPS) support, conformal coating, Local Key Operation, LG CreateBoard Share |
| Operation Hours / Days | 16 / 7 |
| Additional Features | Wake On LAN, infrared multitouch technology, 10-bit (8-bit + FRC), Over-the-Air Update (OTA) |
| Connections | |
| Connector Type | 2 x HDMI input ¦ Infrared input ¦ Audio input ¦ RS-232C input ¦ LAN input ¦ 4 x USB 3.0 ¦ USB-C with 65W Power Delivery ¦ 2 x touch ¦ LAN output |
| Remote Control | |
| Type | Remote control |
| Audio System | |
| Speaker System | 2 speakers |
| Output Power / Total | 32 Watt |
| Speakers | 2 x speaker - 16 Watt |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 73.3 in |
| Depth (Shipping) | 8.9 in |
| Height (Shipping) | 45.2 in |
| Network & Internet Multimedia | |
| Connectivity | LAN |
| LAN Protocol | Ethernet |
| Stands & Mounts | |
| Flat Panel Mount Interface | 600 x 400 mm |
| VESA Compatibility | Yes |
| Media Player | |
| USB Port | Yes |
| USB Ports Qty | 5 |
