OPS Slot-in PC 1 x Core i3 i3-1315U / up to 4.5 GHz - RAM 8 GB - SSD 256 GB - UHD Graphics - Gigabit Ethernet, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6E) - Chrome OS - monitor: none
| Main Specifications | |
|---|---|
| Product Description | AOpen Chromebox OPS BP5130 - OPS Slot-in PC Core i3 i3-1315U 1.2 GHz - 8 GB - SSD 256 GB |
| Type | Chromebox - OPS Slot-in PC |
| Processor | 1 x Intel Core i3 (13th Gen) i3-1315U / 1.2 GHz (up to 4.5 GHz, (6-core) |
| Cache Memory | 10 MB |
| Cache Per Processor | 10 MB |
| RAM | 8 GB (installed) / 8 GB (max) - DDR4 SDRAM |
| Hard Drive | SSD 256 GB |
| Optical Storage | No optical drive |
| Graphics Controller | Intel UHD Graphics |
| Networking | 1GbE, 802.11a, 802.11b/g/n, Wi-Fi 5, Bluetooth 5.2, Wi-Fi 6E |
| OS Provided | Google Chrome OS |
| Dimensions (WxDxH) | 7.9 in x 4.7 in x 1.2 in |
| Weight | 1.54 lbs |
| General | |
| Type | Chromebox |
| Product Form Factor | OPS Slot-in PC |
| Built-in Devices | Power LED |
| Expansion / Connectivity | |
| Interfaces | 4 x USB 2.0 (2 front, 2 rear) ¦ 3 x USB 3.2 Gen 1 (2 front, 1 rear) ¦ 1 x USB-C ¦ 3 x HDMI (1 front, 2 rear) ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x headphones/microphone ¦ 2 x antenna |
| Miscellaneous | |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| Compliant Standards | RoHS, FCC, UL |
| RAM | |
| Installed Size | 8 GB (installed) / 8 GB (max) |
| Technology | DDR4 SDRAM |
| Rated Memory Speed | 3200 MT/s |
| Form Factor | SO-DIMM 260-pin |
| Networking | |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Wi-Fi 6E AX 211 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6E) |
| Power | |
| Voltage Required | DC 12 - 19 V |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 93% RH |
| Cache Memory | |
| Installed Size | 10 MB |
| Cache Per Processor | 10 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel UHD Graphics |
| Video Interfaces | HDMI |
| Operating System / Software | |
| OS Provided | Google Chrome OS |
| Hard Drive | |
| Type | SSD |
| Capacity | 1 x 256 GB |
| Dimensions & Weight | |
| Width | 7.9 in |
| Depth | 4.7 in |
| Height | 1.2 in |
| Weight | 1.54 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 2.34 lbs |
| Processor / Chipset | |
| CPU | Intel Core i3 (13th Gen) i3-1315U |
| Clock Speed | 1.2 GHz |
| Max Turbo Speed | 4.5 GHz (P-core) / 3.3 GHz (E-core) |
| Number of Cores | 6-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
