Switch - smart - 24 x 10/100/1000 + 2 x Gigabit SFP - rack-mountable
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite series - switch - 26 ports - smart - rack-mountable |
| Device Type | Switch - 26 ports - smart |
| Enclosure Type | Rack-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 + 2 x Gigabit SFP |
| Performance | Switching capacity: 52 Gbps |
| MAC Address Table Size | 8000 entries |
| Jumbo Frame Support | 9000 bytes |
| Remote Management Protocol | SNMP, RMON, DHCP |
| Features | Flow control, VPN support, auto-negotiation, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), STP support, RSTP support, DHCP snooping, ACL support, QoS, Port Security, tagged VLAN, 802.1x authentication, crossover detection, metal housing, Storm Control, IPMB, fanless, CoS, full duplex capability, MAC address auto-learning |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1w, IEEE 802.1x |
| Power | AC 100-240 V |
| Dimensions (WxDxH) | 17.3 in x 8.1 in x 1.7 in |
| Weight | 5.4 lbs |
| Color | Black |
| Manufacturer Warranty | 5-year warranty |
| General | |
| Device Type | Switch - 26 ports - smart |
| Enclosure Type | Rack-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 + 2 x Gigabit SFP |
| Performance | Switching capacity: 52 Gbps |
| MAC Address Table Size | 8000 entries |
| Jumbo Frame Support | 9000 bytes |
| Remote Management Protocol | SNMP, RMON, DHCP |
| Features | Flow control, VPN support, auto-negotiation, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), STP support, RSTP support, DHCP snooping, ACL support, QoS, Port Security, tagged VLAN, 802.1x authentication, crossover detection, metal housing, Storm Control, IPMB, fanless, CoS, full duplex capability, MAC address auto-learning |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1w, IEEE 802.1x |
| Status Indicators | Port status, power, SFP |
| Expansion / Connectivity | |
| Interfaces | 24 x 10/100/1000Base-T RJ-45 ¦ 2 x Gigabit LAN SFP uplink |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Color | Black |
| Included Accessories | 4 rubber feet |
| Rack Mounting Kit | Included |
| Compliant Standards | Plug and Play, RoHS, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 100-240 V |
| Power Consumption Operational | 80 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% RH (non-condensing) |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 158 °F |
| Dimensions & Weight | |
| Width | 17.3 in |
| Depth | 8.1 in |
| Height | 1.7 in |
| Weight | 5.4 lbs |
