36" multifunction printer - color - ink-jet - Roll (91.7 cm x 18 m) (original) - Roll (36.1 in) (media) - USB 3.0, USB, Gigabit LAN, Wi-Fi(n), USB 3.2, USB 2.0
| Main Specifications | |
|---|---|
| Product Description | Canon imagePROGRAF TX-3200 MFP Z36 - multifunction printer - color |
| Device Type | 36" multifunction printer |
| Printing Technology | Ink-jet (color) |
| Inkjet Technology | Canon FINE (Full-lithography inkjet Nozzle Engineering) - 5-ink |
| Max Printing Resolution | 2400 x 1200 dpi (color) |
| Scanning | 1200 dpi |
| Original Size | Roll (91.7 cm x 18 m) (max) |
| Original Type | Sheets |
| Media Size | Roll (36.1 in) (max) |
| Media Type | Plain paper |
| Connection Availability | Yes |
| Interface | USB 3.0, USB, Gigabit LAN, Wi-Fi(n), USB 3.2, USB 2.0 |
| Power | AC 100-240 V |
| Dimensions (WxDxH) | 54.3 in x 30.2 in x 45.7 in |
| Weight | 231.48 lbs |
| Environmental Standards | EPEAT Gold, ENERGY STAR Qualified |
| General | |
| Device Type | 36" multifunction printer |
| Printing Technology | Ink-jet - color |
| Connection Availability | Yes |
| Interface | USB 3.0, USB, Gigabit LAN, Wi-Fi(n), USB 3.2, USB 2.0 |
| Memory | |
| Standard Memory | 2 GB |
| Hard Disk Drive | 500 GB |
| Miscellaneous | |
| Compliant Standards | FCC Part 15 B, FCC Part 15 C |
| Power | |
| Voltage Required | AC 100-240 V |
| Power Consumption Operational | 86 Watt |
| Power Consumption Standby | 1.7 Watt |
| Environmental Parameters | |
| Sound Emission | 35 dBA (idle) / 51 dBA (operating) |
| Min Operating Temperature | 59 °F |
| Max Operating Temperature | 86 °F |
| Humidity Range Operating | 10 - 80% (non-condensing) |
| Connections | |
| Interfaces | 1 x USB 3.0 - Type B ¦ USB - Type A ¦ 1 x Gigabit LAN - RJ-45 ¦ 4 x USB 3.2 - Type A ¦ 1 x USB 2.0 - Type A |
| Operating System Support | MS Windows 7 (32/64 bits), Windows 8.1 (32/64-bits), Windows 10 (32/64-bits), Windows 11, MS Windows Server 2008 R2, MS Windows Server 2012, MS Windows Server 2012 R2, MS Windows Server 2016, MS Windows Server 2019, MS Windows Server 2022, macOS 10.15.7 - 14 |
| Software Included | Canon SmartWorks MFP |
| Printing | |
| Inkjet Technology | Canon FINE (Full-lithography inkjet Nozzle Engineering) |
| Nozzle Configuration | 15360 nozzles |
| Max Printing Resolution | 2400 x 1200 dpi (color) |
| Ink Cartridge Configuration | 5 individual ink tanks |
| Ink Palette Supported (Colors) | Cyan, magenta, yellow, black, matte black |
| Color | 5-ink |
| Minimum Ink Droplet Size | 5 pl |
| Printer Drivers / Emulations | Swift Graphic Raster (SGRaster), HPGL/2, HP-RTL, PDF, JPEG |
| Scanning | |
| Scan Element | CIS |
| Optical Resolution | 1200 dpi |
| Color Depth | 24-bit |
| Document & Media Handling | |
| Max Original Size | Roll (91.7 cm x 18 m) |
| Original Type | Sheets |
| Max Media Size | Other |
| Media Thickness Range | 0.0028 in - 0.0315 in |
| Supported Media Type | Plain paper |
| Supported Media Sizes | Roll (6 in), Roll (36.1 in) |
| Document & Media Handling Details | Input tray - 1 roll |
| Dimensions & Weight | |
| Width | 54.3 in |
| Depth | 30.2 in |
| Height | 45.7 in |
| Weight | 231.48 lbs |
| Environmental Standards | |
| EPEAT Compliant | EPEAT Gold |
| ENERGY STAR Certified | Yes |
