SFF Core i5 i5-14500 / up to 5 GHz - RAM 16 GB - SSD 512 GB - NVMe, TLC - UHD Graphics 770 - Gigabit Ethernet - Win 11 Pro - monitor: none - keyboard: US - jack black
| Main Specifications | |
|---|---|
| Product Description | HP Elite 800 G9 - SFF Core i5 i5-14500 - 16 GB - SSD 512 GB - US |
| Type | Personal computer - SFF |
| EU Data Act | Https://compliance-euda.hp.com/ |
| Localization | Language: English / region: United States |
| Processor | Intel Core i5 (14th Gen) i5-14500 (up to 5 GHz, (14-core) |
| Processor Main Features | Intel Turbo Boost Technology, 20 Threads |
| Cache Memory | 24 MB L3 cache |
| Cache Per Processor | 24 MB |
| RAM | 16 GB DDR5 SDRAM |
| Hard Drive | SSD 512 GB - PCI Express 5.0 - M.2 - NVM Express (NVMe), triple-level cell (TLC) |
| Optical Storage | No optical drive |
| Graphics Controller | Intel UHD Graphics 770 |
| Networking | 1GbE |
| Keyboard | US |
| OS Provided | Windows 11 Pro |
| Software Included | HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP Client Catalog (free download), HP Image Assistant, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Sure Admin, HP Client Management Script Library (free download), myHP, Touchpoint Customizer for Commercial, HSA Fusion for Commercial, HSA Telemetry for Commercial, HP Desktop Support Utilities, HP Client Security Manager Gen7, HP Easy Clean, Absolute Persistence Module, HP Smart Support, HP Manageability Integration Kit (free download), HP Connect for Microsoft Endpoint Manager, HP Patch Assistant (free download), HP Sure Recover Gen5, HP Sure Sense Gen2, HP Sure Run Gen5, HP PC Hardware Diagnostics Windows, HP Easy Clean Keyboard Driver, HP CECP Enabled Configuration, HP Sure Start Gen7, HP Driver Packs (free download), HP UEFI BIOS Certification level 2.7B |
| Color | Jack black |
| Dimensions (WxDxH) | 13.3 in x 12.1 in x 3.9 in |
| Weight | 11.9 lbs |
| Carbon Footprint | 232.759 kg carbon emissions |
| General | |
| Type | Personal computer |
| EU Data Act | Https://compliance-euda.hp.com/ |
| Product Form Factor | SFF |
| Sensors | HP Tamper Lock |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Color | Jack black |
| Localization | Language: English / region: United States |
| Expansion / Connectivity | |
| Bays | 2 internal 3.5" |
| Slots | 2 M.2 Card - 2280 (for internal storage) ¦ 1 M.2 Card - 2230 (for WLAN) ¦ 2 PCIe 3.0 x1 ¦ 1 PCIe 3.0 x16 (x4 mode) ¦ 1 PCIe 4.0 x16 |
| Interfaces | 1 x headphones/microphone (1 front) ¦ 4 x USB 3.2 Gen 2 (4 front) ¦ 1 x USB-C 3.2 Gen 2x2 (1 front) ¦ 1 x audio line-out/line-in (1 rear) ¦ 1 x LAN - RJ-45 (1 rear) ¦ 1 x HDMI (1 rear) ¦ 3 x USB 3.2 Gen 1 (3 rear) ¦ 2 x DisplayPort (2 rear) ¦ 3 x USB 2.0 (3 rear) |
| Miscellaneous | |
| Theft/Intrusion Protection | Chassis intrusion sensor |
| Compliant Standards | FIPS 140-2 Level 2, Common Criteria EAL4+ |
| RAM | |
| Installed Size | 16 GB |
| Technology | DDR5 SDRAM |
| Effective Memory Speed | 4800 MT/s |
| Form Factor | DIMM 288-pin |
| Slots | 4 (total) / 3 (empty) |
| Features | Unbuffered |
| Configuration Features | 1 x 16 GB |
| Networking | |
| Ethernet Controller | Intel I219-LM |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Power | |
| Device Type | Power adapter |
| Power Provided | 260 watt |
| Efficiency | 92% |
| Power Factor Correction | Yes (active) |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 10 - 90% RH |
| Cache Memory | |
| Installed Size | L3 cache - 24 MB |
| Cache Per Processor | 24 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel UHD Graphics 770 |
| Video Interfaces | HDMI, DisplayPort |
| Operating System / Software | |
| OS Provided | Windows 11 Pro English |
| Software | HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP Client Catalog (free download), HP Image Assistant, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Sure Admin, HP Client Management Script Library (free download), myHP, Touchpoint Customizer for Commercial, HSA Fusion for Commercial, HSA Telemetry for Commercial, HP Desktop Support Utilities, HP Client Security Manager Gen7, HP Easy Clean, Absolute Persistence Module, HP Smart Support, HP Manageability Integration Kit (free download), HP Connect for Microsoft Endpoint Manager, HP Patch Assistant (free download), HP Sure Recover Gen5, HP Sure Sense Gen2, HP Sure Run Gen5, HP PC Hardware Diagnostics Windows, HP Easy Clean Keyboard Driver, HP CECP Enabled Configuration, HP Sure Start Gen7, HP Driver Packs (free download), HP UEFI BIOS Certification level 2.7B |
| Hard Drive | |
| Type | SSD - M.2 |
| Capacity | 1 x 512 GB |
| Interface Type | PCI Express 5.0 |
| Features | NVM Express (NVMe), triple-level cell (TLC) |
| Input Device | |
| Type | Mouse, keyboard |
| Dimensions & Weight | |
| Width | 13.3 in |
| Depth | 12.1 in |
| Height | 3.9 in |
| Weight | 11.9 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 15.7 in |
| Shipping Depth | 19.6 in |
| Shipping Height | 9 in |
| Shipping Weight | 17.46 lbs |
| Keyboard | |
| Keyboard Name | HP 320K |
| Interface | USB |
| Localization & Layout | US |
| Mouse | |
| Mouse Name | HP 125 |
| Interface | USB |
| Processor / Chipset | |
| CPU | Intel Core i5 (14th Gen) i5-14500 |
| Max Turbo Speed | 5 GHz |
| Number of Cores | 14-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Processor Main Features | Intel Turbo Boost Technology, 20 Threads |
| Chipset Type | Intel Q670 |
| Sustainability Information | |
| Carbon Footprint | 232.759 kg carbon emissions |
| Manufacturing (kg CO2e) | 200.02 |
| Logistics (kg CO2e) | 1.857 |
| Use (kg CO2e) | 29.697 |
| EOL (kg CO2e) | 1.185 |
| Total Carbon w/o Use Phase (kg CO2e) | 203.062 |
