Document scanner - 2 x Contact Image Sensor (CIS) - Duplex - 215.9 x 3048 mm - 1200 dpi - up to 30 ppm (mono) / up to 30 ppm (color) - ADF (60 sheets) - up to 3000 scans per day - USB 2.0
| Main Specifications | |
|---|---|
| Product Description | Epson WorkForce DS-1730 - document scanner - desktop - USB 2.0 |
| Device Type | Document scanner - desktop |
| Interface Type | USB 2.0 |
| Scanning Sensor Type | 2 x Contact Image Sensor (CIS) |
| Light Source | 3-color RGB LED |
| Additional Functions | Scan to email, scan to online storage accounts |
| Max Supported Document Size | 215.9 x 3048 mm |
| Input Type | Color |
| Grayscale / Color Depth | 10-bit gray / 30-bit color |
| Grayscale / Color Depth (External) | 8-bit (256 gray levels) / 24-bit (16.7 million colors) |
| Optical Resolution | 1200 dpi |
| Interpolated Resolution | 1200 dpi |
| Max Document Scan Speed | 30 ppm (mono) / 30 ppm (color) |
| Max Document Size | 8.5 in x 120 in |
| Automatic Duplexing | Yes |
| Supported Document Type | Plain paper, bulk objects (such as books, magazines and other bound materials) |
| Document Feeder Type | Automatic |
| Feeder Capacity | 60 sheets |
| Duty Cycle | 3000 scans per day |
| Power | AC 100-240 V (50 - 60 Hz) |
| System Requirements | Apple MacOS X 10.7.5, Microsoft Windows 7 / 8 / 8.1 / 10 / 11, Apple macOS 15 |
| Dimensions (WxDxH) | 16.7 in x 13.8 in x 5.6 in |
| Weight | 10.6 lbs |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | 1-year warranty |
| General | |
| Type | Document scanner - desktop |
| Interface Type | USB 2.0 |
| Additional Functions | Scan to email, scan to online storage accounts |
| Max Supported Document Size | 215.9 x 3048 mm |
| Expansion / Connectivity | |
| Interfaces Details | USB 2.0 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - advanced exchange program - 1 year - response time: next business day ( for requests before 3:00 p.m.) |
| Miscellaneous | |
| Cables Included | 1 x USB cable |
| Compliant Standards | RoHS, SmartWay |
| Media Handling | |
| Max Document Size | 8.5 in x 120 in |
| Supported Document Type | Plain paper, bulk objects (such as books, magazines and other bound materials) |
| Supported Document Size Details | ADF - up to 215.9 x 3048 mm ¦ Flatbed - up to 8.5 in x 11.69 in |
| Document Feeder Type | Automatic |
| Feeder Capacity | 60 sheets |
| Power | |
| Voltage Required | AC 100-240 V (50 - 60 Hz) |
| Power Consumption Operational (Standby) | 9 watt |
| Power Consumption Stand by | 3.8 watt |
| Power Consumption Sleep | 0.9 watt |
| Software / System Requirements | |
| Software Included | EPSON Document Capture Pro, EPSON Scan 2, Epson Device Admin, EPSON Document Capture for Mac |
| OS Required | Apple MacOS X 10.7.5, Microsoft Windows 7 / 8 / 8.1 / 10 / 11, Apple macOS 15 |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 15 - 80% (non-condensing) |
| Scanner | |
| Input Type | Color |
| Grayscale Depth | 10-bit gray |
| Grayscale Depth (External) | 8-bit (256 gray levels) |
| Color Depth | 30-bit color |
| Color Depth (External) | 24-bit (16.7 million colors) |
| Optical Resolution | 1200 dpi |
| Interpolated Resolution | 1200 dpi |
| Scan Mode | Single-pass |
| Automatic Duplexing | Yes |
| Scanning Sensor Type | 2 x Contact Image Sensor (CIS) |
| Lamp / Light Source Type | 3-color RGB LED |
| Max Document Scan Speed B/W | 30 ppm |
| Max Document Scan Speed Color | 30 ppm |
| Control Panel Buttons Functions | Scan, stop |
| Duty Cycle | 3000 scans per day |
| Scanner Speed Details | 30 ppm - black&white - Letter - 200 - 300 dpi ¦ 30 ppm - color - Letter - 200 - 300 dpi ¦ 60 ipm - duplex - black&white - Letter - 200 - 300 dpi ¦ 60 ipm - duplex - color - Letter - 200 - 300 dpi ¦ 7 sec/scan - black&white - Letter - 200 - 300 dpi ¦ 7 sec/scan - color - Letter - 200 - 300 dpi |
| Scanner Features | Automatic Image Orientation, Mixed Document Feeding, automatic color detection, blank page skipping, Text Enhancement, Punch Hole Removal, Continuous Scanning, Image Correction, skew correction, Unsharp Mask, dual image output, edge fill, watermark adding, background pattern removal, De-Screen, Color Dropout & Enhance, Image Stitching |
| Compliant Standards | TWAIN, ISIS |
| Dimensions & Weight | |
| Width | 16.7 in |
| Depth | 13.8 in |
| Height | 5.6 in |
| Weight | 10.6 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 19.8 in |
| Shipping Depth | 8.6 in |
| Shipping Height | 18.7 in |
| Shipping Weight | 14.31 lbs |
| Environmental Standards | |
| EPEAT Compliant | EPEAT Bronze |
| ENERGY STAR Certified | Yes |
