Server - rack-mountable 2U - 2-way - no CPU - NVMe - hot-swap 2.5" bay(s) - SSD - AST2600 - 10 Gigabit Ethernet, Gigabit Ethernet - no OS - monitor: none
| Main Specifications | |
|---|---|
| Product Description | MiTAC B8261T85E8HR-2T-N - rack-mountable no CPU - SSD |
| Type | Server - rack-mountable |
| Height (Rack Units) | 2U |
| Server Scalability | 2-way |
| Processor | No CPU |
| Processor Socket | Socket SP5 |
| RAM | 6144 GB (max) - DDR5 SDRAM |
| Server Storage Bays | Hot-swap 2.5" |
| Hard Drive | SSD (hot-swap) - PCI Express (NVMe) / U.2 |
| Optical Storage | No optical drive |
| Graphics Controller | ASPEED AST2600 |
| Networking | 10GbE, 1GbE |
| Power Redundancy | Yes |
| OS Provided | No operating system |
| Dimensions (WxDxH) | 17.6 in x 33.5 in x 3.4 in |
| General | |
| Type | Server |
| Product Form Factor | Rack-mountable - 2U |
| Built-in Devices | 6 x hot-swap fans, 2 x rear fans |
| Sensors | Temperature sensor, voltage sensor |
| Server Scalability | 2-way |
| Internal Bays Qty | 8 |
| Front Accessible Bays Qty | 8 |
| Hot-Swap Bays Qty | 8 |
| Expansion / Connectivity | |
| Slots | 6 PCIe 5.0 x16 |
| Interfaces | 4 x USB 3.2 Gen 1 (2 front, 2 rear) ¦ 1 x VGA - DB-15 ¦ 2 x LAN (10Gigabit Ethernet) - RJ-45 ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 |
| Miscellaneous | |
| Compliant Standards | FCC SDOC Class A, DOC-A, RoHS |
| RAM | |
| Installed Size | 6144 GB (max) |
| Technology | DDR5 SDRAM |
| Effective Memory Speed | 6000 MHz |
| Rated Memory Speed | 6000 MHz |
| Slots | 24 (total) / 24 (empty) |
| Networking | |
| Ethernet Ports | 2 x 10 Gigabit Ethernet, 1 x Gigabit Ethernet |
| Ethernet Controller | Intel X550-AT2, Realtek RTL8211F |
| Data Link Protocol | 10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | IPMI 2.0 |
| Remote Management Controller | Aspeed AST2600 |
| Power | |
| Device Type | Power supply |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Voltage Required | AC 100-127/200-240 V |
| Power Provided | 2700 watt |
| 80 PLUS Certification | 80 PLUS Titanium |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 90% (non-condensing) |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | ASPEED AST2600 |
| Video Interfaces | VGA |
| Operating System / Software | |
| OS Provided | No operating system |
| Hard Drive | |
| Type | SSD - hot-swap |
| Interface Type | PCI Express (NVMe) / U.2 |
| Dimensions & Weight | |
| Width | 17.6 in |
| Depth | 33.5 in |
| Height | 3.4 in |
| Processor / Chipset | |
| CPU | No CPU |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
| CPU Socket | Socket SP5 |
| Motherboard Name | Tyan S8261GM2NE-2T |
