Power supply (internal) - ATX12V 2.52 - 80 PLUS Bronze - 550 Watt
| Main Specifications | |
|---|---|
| Product Description | ASRock Challenger CL-550B - power supply - 550 watt |
| Device Type | Power supply - internal |
| Specification Compliance | ATX12V 2.52 |
| 80 PLUS Certification | 80 PLUS Bronze |
| Power Capacity | 550 watt |
| Output connectors | 1 x power 24 pin ATX ¦ 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 2 x 8 pin PCI Express power ¦ 2 x Molex ¦ 4 x SATA connector |
| Modular Cable Management | Yes |
| Cooling System | 120 mm fan |
| Dimensions (WxDxH) | 5.5 in x 5.9 in x 3.4 in |
| Manufacturer Warranty | 5-year warranty |
| General | |
| Device Type | Power supply - internal |
| Specification Compliance | ATX12V 2.52 |
| PSU Form Factor | ATX |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Cables Included | Power 24 pin ATX with detachable 4 pin section modular cable 2 ft ¦ Power 8 pin CPU cable 2 ft ¦ 8 pin PCI Express power cable 2.5 ft ¦ SATA Express cable 2 ft ¦ Parallel cable 2 ft |
| MTBF | 100,000 hours |
| Cooling System | 120 mm fan |
| Features | Sleeved cables, overpower protection, overcurrent protection, short-circuit protection, overvoltage protection, undervoltage protection, high temperature protection |
| Power Device | |
| Power Output Connectors Details | 1 x power 24 pin ATX ¦ 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 2 x 8 pin PCI Express power ¦ 2 x Molex ¦ 4 x SATA connector |
| Power Capacity | 550 watt |
| Modular Cable Management | Yes |
| 80 PLUS Certification | 80 PLUS Bronze |
| Dimensions & Weight | |
| Width | 5.5 in |
| Depth | 5.9 in |
| Height | 3.4 in |
