Speaker - 150 Watt - 2-way - coaxial - black, RAL 9005
| Main Specifications | |
|---|---|
| Product Description | Bose DesignMax DM8SE - speaker |
| Product Type | Speaker |
| Protection | UV radiation resistant, weather-resistant |
| Speaker Type | Coaxial - 2-way - passive |
| Continuous Power | 150 watt |
| Peak Power | 600 watt |
| Nominal Impedance | 8 ohm |
| Integrated Transformer | 70V/100V or 8 Ohm operation |
| Color | Black, RAL 9005 |
| Dimensions (WxDxH) | 9.8 in x 10 in x 15.6 in |
| Weight | 22.71 lbs |
| General | |
| Product Type | Speaker |
| Protection | UV radiation resistant, weather-resistant |
| Enclosure Color | Black, RAL 9005 |
| Enclosure Material | Plastic, powder-coated aluminum |
| Design Features | Paintable |
| Miscellaneous | |
| Included Accessories | U-bracket, input panel cover |
| Compliant Standards | UL 1480A, UL 2239, NFPA 70, IEC 529/IP55 |
| Environmental Parameters | |
| Min Operating Temperature | -13 °F |
| Max Operating Temperature | 158 °F |
| Connections | |
| Connector Type | Speaker input (6-pin Euroblock) |
| Dimensions & Weight | |
| Width | 9.8 in |
| Depth | 10 in |
| Height | 15.6 in |
| Weight | 22.71 lbs |
| Dimensions (WxDxH) / Weight Details | Speaker with bracket: 9.8 in x 10.7 in x 15.6 in |
| Speaker System | |
| Speaker Type | Coaxial - 2-way - passive |
| Continuous Power | 150 watt |
| Peak Power | 600 watt |
| Frequency Response (-3dB) | 60 - 20000 Hz |
| Frequency Response (-10dB) | 52 - 20000 Hz |
| Nominal Impedance | 8 ohm |
| Max Output Level (Max SPL) | 115 dB |
| Sensitivity | 93 dB (1W@1m) |
| Crossover Frequency | 1500 Hz |
| Integrated Transformer | 70V/100V or 8 Ohm operation |
| Coverage | 130° conical |
| Recommended Placing | Outdoor, bracket mount |
| Speaker System Details | |
| Driver Details | Speaker: woofer driver - 8" ¦ Speaker: tweeter driver - 1" - compression driver |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 29.1 lbs |
