Antenna - shark fin - navigation, cellular, Wi-Fi, radio - 32.3 dBi (top band), 26.3 dBi (low band) - omni-directional - roof-mountable, vehicle
| Main Specifications | |
|---|---|
| Product Description | Taoglas Raptor X - antenna |
| Device Type | Antenna |
| Form Factor | Shark fin |
| Intended For | Navigation, cellular, Wi-Fi, radio |
| Antenna Placing / Mounting | Roof-mountable, vehicle |
| Dimensions (WxDxH) | 2.8 in x 13.8 in x 1.5 in |
| Weight | 29.63 oz |
| Compatibility | GPS, GLONASS, GALILEO, BeiDou, l-band, QZSS, SBAS, Wi-Fi, 4G, 5G |
| Frequency Range | 617 - 698 MHz, 1427 - 1518 MHz, 1710 - 2200 MHz, 2300 - 2690 MHz, 2400 - 2500 MHz, 3300 - 5000 MHz, 5150 - 5925 MHz, 698 - 824 MHz, 824 - 960 MHz |
| Gain | 32.3 dBi (top band), 26.3 dBi (low band) |
| Directivity | Omni-directional |
| Features | IP69K, right-hand circular polarization (RHCP), RoHS, VSWR 2:1, linear polarization, IK10, REACH |
| General | |
| Product Type | Antenna |
| Form Factor | Shark fin |
| Intended For | Navigation, cellular, Wi-Fi, radio |
| Antenna Placing / Mounting | Roof-mountable, vehicle |
| Width | 2.8 in |
| Depth | 13.8 in |
| Height | 1.5 in |
| Weight | 29.63 oz |
| Product Material | Polycarbonate (PC) |
| Miscellaneous | |
| Cables Included | Antenna cable - 66 ft |
| Antenna | |
| Compatibility | GPS, GLONASS, GALILEO, BeiDou, l-band, QZSS, SBAS, Wi-Fi, 4G, 5G |
| Frequency Range | 617 - 698 MHz, 1427 - 1518 MHz, 1710 - 2200 MHz, 2300 - 2690 MHz, 2400 - 2500 MHz, 3300 - 5000 MHz, 5150 - 5925 MHz, 698 - 824 MHz, 824 - 960 MHz |
| Impedance | 50 ohm |
| Gain | 32.3 dBi (top band), 26.3 dBi (low band) |
| Directivity | Omni-directional |
| Features | IP69K, right-hand circular polarization (RHCP), RoHS, VSWR 2:1, linear polarization, IK10, REACH |
| Connector Provided | |
| Type | GPS antenna - SMA (male) ¦ 4 x cellular antenna - SMA (male) ¦ 2 x Wi-Fi antenna - RP-SMA (male) |
