LED monitor - 17" - open frame - touchscreen - 1280 x 1024 - 250 cd/m² - HDMI, VGA, DisplayPort
| Main Specifications | |
|---|---|
| Product Description | Advantech FPM-217 - LED monitor - 17" |
| Device Type | LED-backlit LCD monitor - 17" - touchscreen |
| Features | Touchscreen |
| Native Resolution | 1280 x 1024 |
| Brightness | 250 cd/m² |
| Color Support | 16.7 million colors |
| Input Connectors | HDMI, VGA, DisplayPort |
| Voltage | DC 12 V |
| Dimensions (WxDxH) | 16.2 in x 2.1 in x 13.5 in |
| Weight | 11.9 lbs |
| Compliant Standards | IP66 front, CB, CCC, BSMI, FCC Class A certified, ERP, ICC, cULus |
| General | |
| Display Type | LED-backlit LCD monitor / TFT active matrix |
| Diagonal Size | 17" |
| Native Resolution | 1280 x 1024 |
| Brightness | 250 cd/m² |
| Color Support | 16.7 million colors |
| Horizontal Viewing Angle | 170 |
| Vertical Viewing Angle | 160 |
| Backlight Technology | LED backlight |
| Features | IP66 front bezel, anti-glare, tempered glass, slim bezel design, die-cast aluminum frame, die-cast magnesium alloy enclosure, 5-Wire Resistive Touch Screen Technology |
| Dimensions (WxDxH) | 16.2 in x 2.1 in x 13.5 in |
| Weight | 11.9 lbs |
| Miscellaneous | |
| Features | Lockable, wall mountable, stand, vibration-resistant |
| Backlight Life | 50,000 hours |
| Compliant Standards | IP66 front, CB, CCC, BSMI, FCC Class A certified, ERP, ICC, cULus |
| Power | |
| Input Voltage | DC 12 V |
| Power Consumption (Max) | 15 Watt |
| Software / System Requirements | |
| OS Required | Microsoft Windows XP, Microsoft Windows XP Embedded, Microsoft Windows CE, Microsoft Windows Vista, Microsoft Windows 7, Windows 8, Windows 10, Linux |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 10 - 95% RH (non-condensing) |
| Connectivity | |
| Interfaces | VGA ¦ HDMI ¦ DisplayPort ¦ USB |
| Input | |
| Type | Touchscreen - touchscreen |
| Movement Detection Technology | Resistive |
