43" Diagonal Class LM Series LED-backlit LCD display - interactive - with touchscreen (multi touch) - Android - 4K UHD (2160p) 3840 x 2160 - Direct LED
| Main Specifications | |
|---|---|
| Product Description | Sharp PN-LM431 LM Series - 43" LED-backlit LCD display - 4K - for interactive communication |
| Product Type | LED-backlit LCD flat panel display with touchscreen (multi touch) |
| Diagonal Class | 43" |
| Commercial Use | Yes - interactive |
| Platform | Android |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Frame Rate & Enhancement Technology | 60 Hz Frequency |
| Video Interface | HDMI |
| HDMI Ports Qty | 3 ports |
| Connectivity | Wi-Fi, LAN, Bluetooth |
| PC Interface | USB-C |
| Technology | VA |
| LCD Backlight Technology | Direct LED |
| Image Aspect Ratio | 16:9 |
| TV Tuner | No tuner |
| Commercial Features | System on Chip (SoC), 45° tilt, Open Pluggable Standard (OPS) support, metal enclosure, Q-SYS Verified Plugin |
| Speaker System | 2 speakers |
| Storage Capacity | 32 GB |
| USB | 6 ports |
| Included Accessories | Remote control, 2 passive pens, sticker, camera bracket, cable clamps, power cable, wireless adapter |
| Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 110 watt |
| Dimensions (WxDxH) - without stand | 39.1 in x 2.9 in x 22.9 in |
| Weight | 46.3 lbs |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Power Consumption Operational | 110 watt |
| Diagonal Class | 43" |
| Commercial Use | Yes - interactive |
| Combined With | Touchscreen (multi touch) |
| Series | LM Series |
| Platform | Android |
| Operating System | Android OS 14 |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI |
| HDMI Ports Qty | 3 ports |
| PC Interface | USB-C |
| Modes | Landscape mode, portrait mode, Eco mode |
| Design | Slim Bezel Design |
| Dimensions | Without stand |
| Width | 39.1 in |
| Depth | 2.9 in |
| Height | 22.9 in |
| Weight | 46.3 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | 2 passive pens, sticker, camera bracket, cable clamps, power cable, wireless adapter |
| Cables Included | USB cable |
| Compliant Standards | Plug and Play, HDCP 2.3, CEC, VESA DPMS, EMC Class B, RoHS, UKCA, ISO 9241-307 Class 1, IEEE 802.1x, CTS-compliant |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 20 - 80% |
| Display | |
| LCD Display Technology | VA |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Image Aspect Ratio | 16:9 |
| Frame Rate & Enhancement Technology | 60 Hz Frequency |
| LCD Backlight Technology | Direct LED |
| Coating | 25% haze, 0.85 mm bonding gap, 3.1 mm glass, 9H Hard |
| Image Contrast Ratio | 4000:1 |
| Brightness | 500 cd/m² |
| Viewing Angle | 178° |
| Viewing Angle (Vertical) | 178° |
| Touchpoints Qty | 20 |
| Response Time | 8 ms |
| Commercial Features | System on Chip (SoC), 45° tilt, Open Pluggable Standard (OPS) support, metal enclosure, Q-SYS Verified Plugin |
| Additional Features | 1.07 billion colors (8-bit+FRC), Pen-On-Paper technology, virtual whiteboard, Windows Ink compatible, Application Lock, infrared multitouch technology, gloved finger input support, zero bonding technology, NaViSet Administrator 2, OSD Rotation, scheduled timer, disable HW buttons, disable IR functionality, Disable USB and LAN Ports |
| Connections | |
| Connector Type | 3 x HDMI input ¦ HDMI output ¦ 3 x USB 3.0 ¦ Service ¦ USB-C 3.0 with DisplayPort 1.4, 65W Power Delivery ¦ USB-C 3.0 with 7.5W Power Delivery ¦ USB 3.0 ¦ Audio line-out ¦ LAN ¦ RS-232 ¦ Remote control input |
| Remote Control | |
| Type | Remote control |
| Battery Form Factor | AAA type |
| Battery Included | Yes |
| Battery Included Qty | 2 |
| Battery Required Qty | 2 |
| Audio System | |
| Speaker System | 2 speakers |
| Output Power / Total | 20 watt |
| Additional Features | Audio Return Channel (ARC) |
| Speakers | 2 x speaker - 10 watt |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 44.9 in |
| Depth (Shipping) | 7.3 in |
| Height (Shipping) | 29.1 in |
| Weight (Shipping) | 63.93 lbs |
| Network & Internet Multimedia | |
| Connectivity | Wi-Fi, LAN, Bluetooth |
| LAN Protocol | Fast Ethernet |
| Wi-Fi Protocol | 802.11a, 802.11b, 802.11g, 802.11n, 802.11ac, 802.11ax |
| Bluetooth Version | Bluetooth 5.3 |
| Encryption | WPA, WPA2, WPA3 |
| Connect & Share | EShare |
| Stands & Mounts | |
| Flat Panel Mount Interface | 400 x 400 mm |
| VESA Compatibility | Yes |
| Media Player | |
| USB Port | Yes |
| USB Ports Qty | 6 |
| Configuration | 4 x ARM Cortex-A73 + 4 x ARM Cortex-A53 - 4 GB - 32 GB |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 8.0 |
