Fiber media converter - 100Mb LAN - 10Base-T, 100Base-TX, 100Base-X - RJ-45 / SC single-mode - up to 7.5 miles - 1310 nm - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | Omnitron OmniConverter GPoE+/S - fiber media converter - 10Mb LAN, 100Mb LAN - TAA Compliant |
| Device Type | Fiber media converter - RJ-45 / SC single-mode |
| Form Factor | External |
| Cabling Type | 10Base-T, 100Base-TX, 100Base-X |
| Data Transfer Rate | 1 Gbps |
| Optical Wave Length | 1310 nm |
| Data Link Protocol | 10Mb LAN, 100Mb LAN |
| Max Transfer Distance | 7.5 miles |
| Power Over Ethernet (PoE) | PoE+ |
| Power | AC 100-240 V |
| Dimensions (WxDxH) | 3.8 in x 4.8 in x 1 in |
| Weight | 16 oz |
| TAA Compliant | Yes |
| Manufacturer Warranty | Limited lifetime warranty |
| General | |
| Device Type | Fiber media converter |
| Form Factor | External |
| Expansion / Connectivity | |
| Interfaces | 2 x Ethernet 10Base-T/100Base-TX - RJ-45 female ¦ 1 x Ethernet 1000Base-T - SC single-mode female x 2 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Miscellaneous | |
| MTBF | 584,000 hours |
| Compliant Standards | UL 62368-1, UL 60950-1, IEC 62368-1, IEC 60950-1, EN 62368-1, EN 60950-1, CAN/CSA-C22.2 No. 62368-1-14, CAN/CSA C22.2 No. 60950-1, UKCA, EN 55032/24, IEC 61000-6-4, IEC 61000-6-2, CISPR 32, FCC 47 CFR Part 15 B Class A, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IP30, BAA, NDAA |
| TAA Compliant | Yes |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 10Base-T, 100Base-TX, 100Base-X |
| Data Link Protocol | 10Mb LAN, 100Mb LAN |
| Data Transfer Rate | 1 Gbps |
| Optical Wave Length | 1310 nm |
| Max Transfer Distance | 7.5 miles |
| Compliant Standards | IEEE 802.3af, IEEE 802.3, IEEE 802.3at |
| Power | |
| Power Over Ethernet (PoE) | PoE+ |
| Power Device | External power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Dimensions & Weight | |
| Width | 3.8 in |
| Depth | 4.8 in |
| Height | 1 in |
| Weight | 16 oz |
