Mini Core i3 i3-14100T / up to 4.4 GHz - RAM 16 GB - SSD 256 GB - NVMe - UHD Graphics 730 - Gigabit Ethernet - Win 10 Pro - monitor: none - keyboard: US - jack black
| Main Specifications | |
|---|---|
| Product Description | HP Pro 400 G9 - mini Core i3 i3-14100T 2.7 GHz - 16 GB - SSD 256 GB - US |
| Type | Personal computer - mini |
| Localization | Language: English / region: United States |
| Processor | Intel Core i3 (14th Gen) i3-14100T / 2.7 GHz (up to 4.4 GHz, (Quad-Core) |
| Processor Main Features | Intel Turbo Boost Technology |
| Cache Memory | 12 MB L3 cache |
| Cache Per Processor | 12 MB |
| RAM | 16 GB (installed) / 64 GB (max) - DDR5 SDRAM |
| Hard Drive | SSD 256 GB - PCI Express - M.2 2280 - NVM Express (NVMe) |
| Optical Storage | No optical drive |
| Graphics Controller | Intel UHD Graphics 730 Dynamic Video Memory Technology |
| Audio Output | Stereo |
| Networking | 1GbE |
| Keyboard | US |
| Power | (50/60 Hz) |
| OS Provided | Windows 10 Pro |
| Software Included | HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP Client Catalog (free download), HP Setup Integrated OOBE, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, HP QuickDrop, HP Client Management Script Library (free download), HP BIOSphere Gen6, myHP, Touchpoint Customizer for Commercial, HP Desktop Support Utilities, HP Image Assistant Gen5 (free download), HP Easy Clean, HP Smart Support (free download), HP Manageability Integration Kit (free download), HP Patch Assistant (free download), HP Sure Start |
| Color | Jack black |
| Dimensions (WxDxH) | 7 in x 6.9 in x 1.3 in |
| Weight | 3.13 lbs |
| Environmental Standards | TCO Certified Desktops 9, ENERGY STAR Qualified EPEAT Gold |
| Manufacturer Warranty | Limited warranty - parts and labor - 1 year - on-site |
| General | |
| Type | Personal computer |
| Product Form Factor | Mini |
| Built-in Devices | Speaker |
| Sensors | HP Tamper Lock |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Color | Jack black |
| Localization | Language: English / region: United States |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x internal 2.5" |
| Slots | 1 (total) / 1 (free) x M.2 Card - 2230 (for wireless module) ¦ 1 (total) / 0 (free) x M.2 Card - 2280 (for internal storage) |
| Interfaces | 1 x headphones/microphone (1 in front) (CTIA headset support) ¦ 2 x USB 3.2 Gen 2 (2 in front) (one of them is charging) ¦ 1 x USB-C 3.2 Gen 2x2 (1 in front) (charging) ¦ 1 x USB 3.2 Gen 2 ¦ 2 x DisplayPort 1.4a ¦ 2 x HDMI ¦ 2 x USB 3.2 Gen 1 (wake functionality) ¦ 1 x LAN (Gigabit Ethernet) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 1 year - on-site |
| Miscellaneous | |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), chassis intrusion sensor, retractable padlock loop |
| Security Slot Type | Kensington security slot |
| Compliant Standards | FCC Class B certified, ICES-003, CCC, FIPS 140-2 Level 2, RoHS, WEEE, KCC Class B, Common Criteria EAL4+, VCCI Class B, low halogen, CAN/CSA-C22.2 No. 62368-1, UL 62368-1, IEEE 1680.1-2018 |
| RAM | |
| Installed Size | 16 GB (installed) / 64 GB (max) |
| Technology | DDR5 SDRAM |
| Effective Memory Speed | 4800 MT/s |
| Rated Memory Speed | 4800 MT/s |
| Form Factor | SO-DIMM 262-pin |
| Slots | 2 (total) / 1 (empty) |
| Configuration Features | 1 x 16 GB |
| Networking | |
| Ethernet Controller | Intel I219-LM |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | SNMP 2 |
| Features | Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support |
| Power | |
| Device Type | Power adapter |
| Voltage Required | AC 90-264 V (50/60 Hz) |
| Power Provided | 90 Watt |
| Efficiency | 89% (230VAC), 88% (115VAC) |
| Power Factor Correction | Yes (active) |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 10 - 90% RH (non-condensing) |
| Cache Memory | |
| Installed Size | L3 cache - 12 MB |
| Cache Per Processor | 12 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel UHD Graphics 730 Dynamic Video Memory Technology |
| Video Interfaces | HDMI, DisplayPort |
| HDCP Compatible | Yes |
| Audio Output | |
| Sound Output Mode | Stereo |
| Max Sampling Rate | 192 kHz |
| Compliant Standards | High Definition Audio |
| Operating System / Software | |
| OS Provided | Windows 10 Pro English |
| Software | HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP Client Catalog (free download), HP Setup Integrated OOBE, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, HP QuickDrop, HP Client Management Script Library (free download), HP BIOSphere Gen6, myHP, Touchpoint Customizer for Commercial, HP Desktop Support Utilities, HP Image Assistant Gen5 (free download), HP Easy Clean, HP Smart Support (free download), HP Manageability Integration Kit (free download), HP Patch Assistant (free download), HP Sure Start |
| Hard Drive | |
| Type | SSD - M.2 2280 |
| Capacity | 1 x 256 GB |
| Interface Type | PCI Express |
| Features | NVM Express (NVMe) |
| Input Device | |
| Type | Mouse, keyboard |
| Dimensions & Weight | |
| Width | 7 in |
| Depth | 6.9 in |
| Height | 1.3 in |
| Weight | 3.13 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 19.6 in |
| Shipping Depth | 9.3 in |
| Shipping Height | 5.2 in |
| Shipping Weight | 7.5 lbs |
| Keyboard | |
| Keyboard Name | HP 320K |
| Interface | USB |
| Localization & Layout | US |
| Mouse | |
| Mouse Name | HP 125 |
| Processor / Chipset | |
| CPU | Intel Core i3 (14th Gen) i3-14100T |
| Clock Speed | 2.7 GHz |
| Max Turbo Speed | 4.4 GHz |
| Number of Cores | Quad-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| L2 cache | 5 MB |
| CPU Upgradability | Upgradable |
| Processor Main Features | Intel Turbo Boost Technology |
| Chipset Type | Intel Q670 |
| Sustainability Information | |
| TCO Certified | TCO Certified Desktops 9 |
| EPEAT Compliant | EPEAT Gold |
| ENERGY STAR Certified | Yes |
