All-in-one with UltraFlex V Stand - Core Ultra 7 265 / up to 5.3 GHz - vPro Enterprise - RAM 32 GB - SSD 512 GB - TCG Opal Encryption 2, NVMe - Intel Graphics - Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7) - Win 11 Pro - monitor: LED 27" 2560 x 1440 (QHD) @ 120 Hz - keyboard: English - black - Lenovo TopSeller
| Main Specifications | |
|---|---|
| Product Description | Lenovo ThinkCentre M90a Pro Gen 6 - all-in-one Core Ultra 7 265 2.4 GHz - vPro Enterprise - 32 GB - SSD 512 GB - LED 27" - English |
| Type | Personal computer - all-in-one |
| Platform Technology | Intel vPro Enterprise |
| Localization | Language: English / region: United States |
| Processor | Intel Core Ultra 7 (Series 2) 265 / 2.4 GHz (up to 5.3 GHz, (20-core) |
| Processor Main Features | Intel Smart Cache |
| Neural Processor Unit (NPU) | Intel AI Boost - up to 13 TOPS |
| Cache Memory | 36 MB |
| Cache Per Processor | 36 MB |
| RAM | 32 GB (installed) / 64 GB (max) - DDR5 SDRAM - non-ECC |
| Storage Controller | RAID (PCI Express (NVMe)) |
| Hard Drive | SSD 512 GB - PCI Express 4.0 x4 - M.2 2280 - TCG Opal Encryption 2, NVM Express (NVMe) |
| Optical Storage | No optical drive |
| Monitor | 27" - LED - 2560 x 1440 (QHD) @ 120 Hz - 16:9 |
| Graphics Controller | Intel Graphics shared video memory (UMA) - up to 8 TOPS |
| Camera | Yes |
| Networking | 1GbE, 802.11a, 802.11b/g/n, Wi-Fi 5, Wi-Fi 6, Bluetooth, Wi-Fi 7 |
| Keyboard | English |
| Power | (50/60 Hz) |
| OS Provided | Windows 11 Pro |
| Color | Black |
| Dimensions (WxDxH) | 24.2 in x 14.3 in x 9.3 in |
| Weight | 24.85 lbs |
| Manufacturer Selling Program | Lenovo TopSeller |
| Environmental Standards | TCO Certified Edge All-in-one computers, TCO Certified, generation 10, for all-in-one PCs, ENERGY STAR Qualified EPEAT Gold |
| Carbon Footprint | 506 kg carbon emissions |
| Manufacturer Warranty | Limited warranty - 3 years - on-site |
| General | |
| Platform Technology | Intel vPro Enterprise |
| Type | Personal computer |
| Product Form Factor | All-in-one - with UltraFlex V Stand |
| Built-in Devices | Stereo speakers |
| Embedded Security | Discrete Trusted Platform Module (TPM 2.0) Security Chip |
| Color | Black |
| Localization | Language: English / region: United States |
| Expansion / Connectivity | |
| Slots | 3 (total) / 2 (free) x M.2 Card (for SSD) ¦ 1 (total) / 0 (free) x M.2 Card (for WLAN) |
| Interfaces | 3 x USB 3.2 Gen 2 (1 side, 2 rear) ¦ 2 x USB 3.2 Gen 1 (2 rear) (one of them supports SmartPower On) ¦ 1 x HDMI (1 rear) (TMDS compatible) ¦ 1 x DisplayPort 1.4a (1 rear) ¦ 1 x LAN (Gigabit Ethernet) (1 rear) ¦ 1 x Thunderbolt 4/USB4/DisplayPort 2.1 (1 side) (Always On, 65W Power Delivery 3.0) ¦ 1 x USB-C 3.2 Gen 2 (1 side) (data transfer, 5V 3A charging) ¦ 1 x headphones/microphone (1 side) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years - on-site |
| Miscellaneous | |
| Included Accessories | VESA mounting kit |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), chassis intrusion switch |
| Security Slot Type | Kensington security slot |
| VESA Mounting Interface | 100 x 100 mm |
| Compliant Standards | RoHS, FIPS 140-2, GREENGUARD, Energy-Related Products (ErP) Lot 3, TUV Rheinland Flicker Free Certification, TCG Certified, TUV Rheinland Low Blue Light (Hardware Solution), Eyesafe Certified 2.0, IP55 front |
| Manufacturer Selling Program | Lenovo TopSeller |
| RAM | |
| Installed Size | 32 GB (installed) / 64 GB (max) |
| Technology | DDR5 SDRAM - non-ECC |
| Effective Memory Speed | 5600 MT/s |
| Rated Memory Speed | 5600 MT/s |
| Form Factor | SO-DIMM 262-pin |
| Slots | 2 (total) / 1 (empty) |
| Features | Dual channel memory architecture |
| Configuration Features | 1 x 32 GB |
| Networking | |
| Interface (Bus) Type | M.2 Card |
| Ethernet Controller | Intel I219-LM |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel WI-FI 7 BE200 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7) |
| Features | Wake on LAN (WoL), dual stream (2x2) |
| Power | |
| Device Type | Power supply |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Provided | 180 Watt |
| Efficiency | 90% |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 20 - 80% |
| Storage Controller | |
| Type | 1 x RAID |
| Controller Interface Type | PCI Express (NVMe) |
| RAID Level | RAID 0, RAID 1 |
| Cache Memory | |
| Installed Size | 36 MB |
| Cache Per Processor | 36 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | LED - IPS |
| Diagonal Size | 27" |
| Native Resolution | 2560 x 1440 (QHD) |
| V-Sync Rate at Max Res. | 120 Hz |
| Widescreen Display | Yes |
| Image Aspect Ratio | 16:9 |
| Horizontal Viewing Angle | +89 / -89 |
| Vertical Viewing Angle | +89 / -89 |
| Color Gamut | 99% sRGB |
| Response Time | 14 ms |
| Image Brightness | 400 cd/m² |
| Monitor Features | Anti-glare, Flicker Free technology, 4 Side Borderless Design, Low Blue Light technology, Eyesafe technology |
| Graphics Controller | |
| Graphics Processor | Intel Graphics shared video memory (UMA) - up to 8 TOPS |
| Video Interfaces | HDMI, DisplayPort, Thunderbolt |
| Max Monitors Supported | 3 |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Speakers Included | 2 x right / left channel |
| Operating System / Software | |
| OS Provided | Windows 11 Pro English |
| Hard Drive | |
| Type | SSD - M.2 2280 |
| Capacity | 1 x 512 GB |
| Interface Type | PCI Express 4.0 x4 |
| Features | TCG Opal Encryption 2, NVM Express (NVMe) |
| Camera | |
| Camera | Yes |
| Resolution (MP) | 5 Megapixel |
| Features | Tilt adjustment, swivel, Windows Hello, hybrid IR camera, ThinkShutter camera cover |
| Audio Input | |
| Type | Dual array microphone |
| Input Device | |
| Type | Mouse, keyboard |
| Dimensions & Weight | |
| Dimensions & Weight Details | 24.2 in - 14.3 in - 9.3 in - 24.8 lbs - with stand (lowest position in flat mode) ¦ 24.2 in - 10.4 in - 18.6 in - 24.8 lbs - with stand (highest position in vertical mode) |
| Width | 24.2 in |
| Depth | 14.3 in |
| Height | 9.3 in |
| Weight | 24.85 lbs |
| Keyboard | |
| Keyboard Name | Lenovo Traditional Keyboard |
| Interface | USB |
| Localization & Layout | English |
| Mouse | |
| Mouse Name | Lenovo Calliope Mouse |
| Interface | USB |
| Processor / Chipset | |
| CPU | Intel Core Ultra 7 (Series 2) 265 |
| Clock Speed | 2.4 GHz (P-core) / 1.8 GHz (E-core) |
| Max Turbo Speed | 5.3 GHz (P-core) / 4.6 GHz (E-core) |
| Number of Cores | 20-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Processor Main Features | Intel Smart Cache |
| Chipset Type | Intel Q870 |
| Sustainability Information | |
| TCO Certified | TCO Certified Edge All-in-one computers, TCO Certified, generation 10, for all-in-one PCs |
| EPEAT Compliant | EPEAT Gold |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 9.0 |
| Carbon Footprint | 506 kg carbon emissions |
| Total CF/unit Standard Deviation (kg CO2e) | 100 |
| PAIA Version | 1.4.6 |
| Neural Processor Unit (NPU) | |
| Neural Processor Unit (NPU) | Intel AI Boost |
| NPU Performance Up To (TOPS) | 13 TOPS |
| Total Processor Performance Up To (TOPS) | 33 TOPS |
| AI Datatype Support on NPU | INT8 |
| Sparsity Support | Yes |
| AI Software Frameworks Supported by NPU | DirectML, OpenVINO, WebNN, WindowsML, ONNX RT |
| Windows Studio Effects Support | Yes |
