Docking station - USB-C / Thunderbolt 3 - HDMI, 2 x DP, USB-C, Thunderbolt - 1GbE - 180 Watt - for Latitude 3390, 3400, 3490, 3590, 5280, 5289, 5290 (2-in-1), 5300 (2-in-1), 5400, 5410, 542X, 5480, 5490, 5500, 5580, 5590, 7280, 7285, 7300, 7380, 7389, 7390 (2-in-1), 7400 (2-in-1), 7480, 7490; Precision 3520, 3530, 3540, 5520, 5530 (2 in 1), 7520, 7530, 7720, 7730; XPS 936X, 9370, 9380, 9560, 9575
| Main Specifications | |
|---|---|
| Product Description | Dell Thunderbolt Dock WD19TB - docking station - USB-C / Thunderbolt 3 - HDMI, 2 x DP, USB-C, Thunderbolt - 1GbE |
| Product Type | Docking station |
| Docking Interface | USB-C / Thunderbolt 3 |
| Video Interfaces | HDMI, 2 x DP, USB-C, Thunderbolt |
| Dimensions (WxDxH) | 8.1 in x 3.5 in x 1.1 in |
| Weight | 20.63 oz |
| Networking | Gigabit Ethernet |
| Power | Power adapter 180 Watt Power Provided |
| Manufacturer Warranty | 3-year warranty |
| Designed For | Latitude 3390, 3400, 3490, 3590, 5280, 5289, 5290 (2-in-1), 5300 (2-in-1), 5400, 5410, 542X, 5480, 5490, 5500, 5580, 5590, 7280, 7285, 7300, 7380, 7389, 7390 (2-in-1), 7400 (2-in-1), 7480, 7490; Precision 3520, 3530, 3540, 5520, 5530 (2 in 1), 7520, 7530, 7720, 7730; XPS 936X, 9370, 9380, 9560, 9575 |
| General | |
| Product Type | Docking station |
| Width | 8.1 in |
| Depth | 3.5 in |
| Height | 1.1 in |
| Weight | 20.63 oz |
| Expansion / Connectivity | |
| Interfaces | 2 x display / video - DisplayPort - 20 pin DisplayPort ¦ 1 x display / video - HDMI - 19 pin HDMI Type A ¦ 1 x USB-C ¦ 3 x SuperSpeed USB 3.0 - 9 pin USB Type A ¦ 2 x USB-C 3.1 Gen 2 ¦ 1 x headset - output - mini-phone 3.5 mm ¦ 1 x speakers - output - mini-phone 3.5 mm ¦ 1 x network - RJ-45 ¦ 1 x Thunderbolt 3 - Thunderbolt - 24 pin USB-C |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - advanced exchange program - 3 years |
| Miscellaneous | |
| Cables Included | 1 x Thunderbolt 3 cable - 2.6 ft |
| Features | Security lock slot (cable lock sold separately), up to 4 monitors support, 130W power delivery to Dell systems, 90W power delivery to non-Dell systems, pass-through MAC address, wireless vPro, on/off switch, modular design |
| Security Slot Type | Noble Wedge security slot / Kensington security slot |
| Compliant Standards | DisplayPort 1.4 |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Power | |
| Power Device | Power adapter |
| Power Provided | 180 Watt |
| Video | |
| Max Resolution Details | 5120 x 2880 - 60 Hz |
| System Requirements | |
| OS Required | Ubuntu 18.04, Windows 10, Red Hat Enterprise Linux |
| Compatibility Information | |
| Designed For | Dell Latitude 3390 2-in-1, 3400, 3490, 3500, 3590, 5280, 5289 2-In-1, 5290, 5290 2-in-1, 5300, 5300 2-in-1, 5400, 5410, 5420 Rugged, 5424 Rugged, 5480, 5490, 5491, 5500, 5580, 5590, 5591, 7280, 7285 2-in-1, 7300, 7380, 7389 2-in-1, 7390, 7390 2-in-1, 7400, 7400 2-in-1, 7480, 7490 ¦ Dell Precision 3520, 3530, 3540, 5520, 5530, 5530 2-in-1, 7520, 7530, 7720, 7730 ¦ Dell XPS 13 9360, 13 9365 2-in-1, 13 9370, 13 9380, 15 7590, 15 9560, 15 9575 2-in-1 |
