Hard drive array - 72 TB - 4 bays (SATA-600) - HDD 18 TB x 4 - Thunderbolt 3, USB 3.2 Gen 2 (external)
| Main Specifications | |
|---|---|
| Product Description | Promise Pegasus32 R4 - hard drive array |
| Device Type | Hard drive array |
| Total Array Capacity | 72 TB |
| Interface | Thunderbolt 3, USB 3.2 Gen 2 |
| Installed Devices / Modules Qty | 4 (installed) / 4 (max) |
| Supported Drives | SATA-600 |
| Storage Controller | RAID (SATA 6Gb/s) - RAID 0, 1, 5, 10, JBOD |
| Hard Drive | 4 x 18 TB HDD SATA 6Gb/s - hot-swap |
| OS Required | Windows 10 64-bit Edition, Apple macOS 10.14 or later |
| Dimensions (WxDxH) | 7.4 in x 9.6 in x 7.6 in |
| Weight | 14.99 lbs |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Hard drive array |
| Expansion / Connectivity | |
| Expansion Bays | 4 (total) / 0 (free) x hot-swap - 3.5" |
| Interfaces | 2 x Thunderbolt 3 / USB 3.2 Gen 2 - 24 pin USB-C ¦ 1 x DisplayPort |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Cables Included | 1 x Thunderbolt 3 / USB-C cable - 2.3 ft |
| Storage | |
| Total Array Capacity | 72 TB |
| HDD Array External Interface | Thunderbolt 3, USB 3.2 Gen 2 |
| Power | |
| Power Device | Internal power supply |
| Storage Controller | |
| Type | RAID |
| Interface Type | SATA 6Gb/s |
| Data Transfer Rate | 600 MBps |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 10, JBOD |
| System Requirements | |
| OS Required | Windows 10 64-bit Edition, Apple macOS 10.14 or later |
| Hard Drive | |
| Type | HDD - hot-swap |
| Capacity | 4 x 18 TB |
| Interface Type | SATA 6Gb/s |
| Dimensions & Weight | |
| Width | 7.4 in |
| Depth | 9.6 in |
| Height | 7.6 in |
| Weight | 14.99 lbs |
| Chassis | |
| Installed Devices / Modules Qty | 4 |
| Supported Devices / Modules Qty | 4 |
| Supported Drives | SATA-600 |
