Meeting room device
| Main Specifications | |
|---|---|
| Product Description | Neat Bar BYOD |
| Device Type | Meeting room device |
| Dimensions (WxDxH) | 21.9 in x 3 in x 3 in |
| Weight | 3.75 lbs |
| Video Input | Digital video camera |
| Audio Input | 5-microphone array - beamforming |
| Audio Output | Speaker(s) |
| Networking | Network adapter - Ethernet, Wi-Fi |
| Power | AC 100-240 V (50/60 Hz) |
| Manufacturer Warranty | 1-year warranty |
| General | |
| Device Type | Meeting room device |
| Width | 21.9 in |
| Depth | 3 in |
| Height | 3 in |
| Weight | 3.75 lbs |
| Built-in Devices | Ambient light sensor, air quality sensor, accelerometer, temperature sensor, CO2 sensor, VOC sensor, speaker, 5 microphone array, 12 megapixel camera |
| Expansion / Connectivity | |
| Interfaces | 1 x audio / video - HDMI input - 19 pin HDMI Type A ¦ 2 x audio / video - HDMI output - 19 pin HDMI Type A ¦ 1 x USB-C - 24 pin USB-C ¦ 1 x network - Ethernet - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year ¦ Return - 30 days |
| Miscellaneous | |
| Cables Included | 1 x HDMI cable - 6.6 ft ¦ 1 x network cable - 10 ft ¦ 1 x power cable - 10 ft |
| Included Accessories | Mount adapter, wall mount, screen mount, table stand, snap-on mount, 8 M6 screw (24mm), 8 M8 screw (24mm), 6 spacers, hex wrench (2mm), hex wrench (5mm) |
| Networking | |
| Type | Network adapter |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Wi-Fi |
| Features | BYOD mode, dual monitor support, security slot (Kensington security lock compatible), secure boot, echo cancellation, noise suppression, automatic gain control (AGC) |
| Power | |
| Power Device | Power supply - internal |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Software / System Requirements | |
| Software Included | Neat Pulse |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 10 - 90% RH |
| Audio Output | |
| Type | Speaker(s) |
| Audio Input | |
| Type | 5-microphone array - integrated |
| Microphone Operation Mode | Beamforming |
| Video Input | |
| Type | Digital video camera - integrated |
| Digital Video Capture Resolution | 4056 x 3040 |
| Digital Zoom | 4 |
| Features | 120° field of view (horizontal), 12 megapixels resolution, automatic people framing, image distortion correction, chromatic aberration correction, auto white balance, auto color correction, hardware accelerated video decode, hardware accelerated video encode, dereverberation |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 29 in |
| Shipping Depth | 11 in |
| Shipping Height | 12 in |
| Shipping Weight | 18.08 lbs |
