AI PC - 180-degree hinge design - Intel Core Ultra 7 - 255H / up to 5.1 GHz - Win 11 Pro - Arc Graphics 140T - 16 GB RAM - 512 GB SSD NVMe - 14" IPS touchscreen 1920 x 1200 - Wi-Fi 6E, Bluetooth - arctic gray - kbd: English
| Main Specifications | |
|---|---|
| Product Description | Lenovo ThinkBook 14 G8 IAL - AI PC - 14" - Intel Core Ultra 7 - 255H - 16 GB RAM - 512 GB SSD - English |
| Product Type | Notebook - AI PC - 180-degree hinge design |
| Operating System | Win 11 Pro - English |
| Processor | Intel Core Ultra 7 (Series 2) - 255H up to 5.1 GHz / 24 MB Cache |
| Neural Processor Unit (NPU) | Intel AI Boost - up to 13 TOPS |
| Memory | 16 GB DDR5 (1 x 16 GB) |
| Storage | 512 GB SSD - NVMe |
| Display | 14" touchscreen 1920 x 1200 / WUXGA @ 60 Hz |
| Graphics | Intel Arc Graphics 140T - up to 74 TOPS |
| Keyboard | English |
| Keyboard Backlight | Yes |
| Integrated Webcam | Yes |
| Networking | 802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.3 |
| Security | Firmware Trusted Platform Module (TPM 2.0) Security Chip, fingerprint reader |
| Color | Arctic gray |
| Dimensions (WxDxH) | 12.3 in x 8.8 in x 0.7 in |
| Weight | 3 lbs |
| Localization | Language: English / region: United States |
| Manufacturer Selling Program | Lenovo TopSeller |
| Environmental Standards | TCO Certified, generation 10, for notebooks, ENERGY STAR Qualified EPEAT Gold |
| Manufacturer Warranty | Limited warranty - 1 year - pick-up and return |
| General | |
| Product Type | Notebook - 180-degree hinge design |
| AI Level | AI PC |
| Operating System | Windows 11 Pro - English |
| Memory | |
| RAM | 16 GB (1 x 16 GB) |
| Max RAM Supported | 64 GB |
| Technology | DDR5 SDRAM |
| Speed | 5600 MT/s |
| Rated Speed | 5600 MT/s |
| Form Factor | SO-DIMM 262-pin |
| Slots Qty | 2 |
| Empty Slots | 1 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year - pick-up and return |
| Miscellaneous | |
| Color | Arctic gray |
| Case Material | Aluminum (top), polycarbonate ABS (bottom) |
| Surface Finish | Anodizing sandblasting (top), texture (bottom) |
| Security | Firmware Trusted Platform Module (TPM 2.0) Security Chip, fingerprint reader |
| Features | MIL-STD-810H tested, Modern Standby |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington nano security slot |
| Included Accessories | USB-C slim wall mount power adapter |
| Compliant Standards | RoHS, Energy-Related Products (ErP) Lot 6, Energy-Related Products (ErP) Lot 26, TUV Rheinland Low Blue Light (Software Solution) |
| Localization | Language: English / region: United States |
| Manufacturer Selling Program | Lenovo TopSeller |
| Storage | |
| Main Storage | 512 GB SSD M.2 2242 PCIe 4.0 x4 - NVM Express (NVMe) |
| Software | |
| Software Included | Microsoft Office (Trial) |
| Battery | |
| Technology | Lithium polymer |
| Capacity | 45 Wh |
| Display | |
| Type | 14" - IPS |
| Touchscreen | Yes (10-point multi-touch) |
| Resolution | 1920 x 1200 (WUXGA) |
| V-Sync Rate at Max Res. | 60 Hz |
| Widescreen | Yes |
| Image Aspect Ratio | 16:10 |
| Image Brightness | 300 cd/m² |
| Color Gamut | 45% NTSC |
| Features | Anti-glare, Low Blue Light technology, Add-on Film Touch |
| Communications | |
| Wireless | 802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.3 |
| Features | Dual stream (2x2) |
| Dimensions & Weight | |
| Dimensions (WxDxH) | 12.3 in x 8.8 in x 0.7 in |
| Weight | 3 lbs |
| Processor / Chipset | |
| CPU | Intel Core Ultra 7 (Series 2) 255H |
| Max Turbo Speed | 5.1 GHz |
| Number of Cores | 16-core |
| Performance Cores | 6 |
| Efficient Cores | 10 |
| Cache | 24 MB |
| Features | Integrated memory controller |
| Audio & Video | |
| Graphics Processor | Intel Arc Graphics 140T - up to 74 TOPS |
| Video System Features | Functions as Intel graphics (for single-channel memory) |
| Camera | Yes - 1080p |
| Camera Features | Privacy shutter, fixed focus |
| Sound | Stereo speakers, dual array microphone |
| Codec | Realtek ALC3287 |
| Compliant Standards | High Definition Audio, Dolby Audio |
| Input | |
| Type | Keyboard, touchpad |
| Keyboard Backlight | Yes |
| Keyboard Layout | English |
| Features | Buttonless touchpad, precision multi-touch touchpad |
| AC Adapter | |
| Input | AC 100-240 V (50/60 Hz) |
| Output | 65 watt |
| Connections & Expansion | |
| Slots | 2 x M.2 (PCI Express 4.0 x4) (1 available) |
| Interfaces Details | USB 3.2 Gen 1 ¦ USB 3.2 Gen 1 (Always On) ¦ USB-C 3.2 Gen 2 (supports DisplayPort 1.4 Alt Mode) (Power Delivery 3.0) ¦ USB4 (supports Thunderbolt 4, DisplayPort 2.1 Alt Mode) (Power Delivery 3.0) ¦ HDMI (4K support) ¦ Headphone/microphone combo jack (mini-phone 3.5 mm) ¦ LAN (RJ-45) |
| Memory Card Reader | Yes (SD Card) |
| Sustainability Information | |
| TCO Certified | - TCO Certified, generation 10, for notebooks |
| EPEAT Compliant | EPEAT Gold |
| ENERGY STAR Certified | Yes |
| Neural Processor Unit (NPU) | |
| Neural Processor Unit (NPU) | Intel AI Boost |
| NPU Performance Up To (TOPS) | 13 TOPS |
| Total Processor Performance Up To (TOPS) | 96 TOPS |
| AI Datatype Support on NPU | INT8 |
| Sparsity Support | Yes |
| AI Software Frameworks Supported by NPU | DirectML, OpenVINO, WebNN, WindowsML, ONNX RT |
| Windows Studio Effects Support | Yes |
