105" Diagonal Class LED-backlit LCD display - interactive digital signage - with touchscreen (multi touch) / 8-microphone array - Android - 5K UHD (2160p) 5120 x 2160 - Direct LED - black
| Main Specifications | |
|---|---|
| Product Description | LG CreateBoard 105TR5WP-B 105" LED-backlit LCD display - 5K - for digital signage / interactive communication |
| Product Type | LED-backlit LCD flat panel display with touchscreen (multi touch) / 8-microphone array |
| Diagonal Class | 105" |
| Commercial Use | Yes - interactive digital signage |
| Color | Black |
| Platform | Android |
| Resolution | 5120 x 2160 |
| Display Format | 5K UHD (2160p) |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| Video Interface | HDMI |
| HDMI Ports Qty | 4 ports |
| Connectivity | Wi-Fi, LAN, Bluetooth |
| PC Interface | USB-C |
| Technology | VA |
| LCD Backlight Technology | Direct LED |
| Image Aspect Ratio | 21:9 |
| TV Tuner | No tuner |
| Commercial Features | Open Pluggable Standard (OPS) support, Network Ready, booting logo image, Local Key Operation, LG CreateBoard Share, Crestron Connected Certified, LG ConnectedCare |
| Picture Enhancements | 72% Color Gamut NTSC |
| Speaker System | 2 speakers |
| Storage Capacity | 64 GB |
| USB | 4 ports |
| Included Accessories | Remote control, Wi-Fi module, 2 styluses |
| Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 315 watt |
| Power Consumption Stand by | 0.5 watt |
| Dimensions (WxDxH) | 98.8 in x 3.6 in x 44.5 in |
| Weight | 186.51 lbs |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Power Consumption (Max) | 560 watt |
| Power Consumption Operational | 315 watt |
| Diagonal Class | 105" |
| Commercial Use | Yes - interactive digital signage |
| Combined With | Touchscreen (multi touch) / 8-microphone array |
| Platform | Android |
| Operating System | Android OS 13 |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Sensors | Auto brightness sensor |
| Video Interface | HDMI |
| HDMI Ports Qty | 4 ports |
| PC Interface | USB-C |
| Modes | Landscape mode |
| Picture Enhancements | 72% Color Gamut NTSC |
| Design | Front Connectivity Design |
| Protection | Tempered glass protection, shatter-resistant |
| Width | 98.8 in |
| Depth | 3.6 in |
| Height | 44.5 in |
| Weight | 186.51 lbs |
| Enclosure Color | Black |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | Wi-Fi module, 2 styluses |
| Cables Included | USB-A to USB-B cable - 16.4 ft ¦ USB-C to USB-C cable - 6 ft ¦ HDMI cable - 10 ft |
| Compliant Standards | CEC, HDCP 2.3, UL, ERP, FCC Class A certified |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Stand by | 0.5 watt |
| Features | Smart energy saving, WOL (Wake on LAN) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% |
| Display | |
| LCD Display Technology | VA |
| Color Support | 1070000000 colors |
| Resolution | 5120 x 2160 |
| Display Format | 5K UHD (2160p) |
| Image Aspect Ratio | 21:9 |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| LCD Backlight Technology | Direct LED |
| Coating | Anti-reflection, 25% haze |
| Image Contrast Ratio | 4000:1 |
| Dynamic Contrast Ratio | 5000:1 |
| Brightness | 400 cd/m² |
| Viewing Angle | 178° |
| Viewing Angle (Vertical) | 178° |
| Touchpoints Qty | 50 |
| Response Time | 6.5 ms |
| Display Menu Language | Multilingual |
| Backlight Life | 50,000 hour(s) |
| Commercial Features | Open Pluggable Standard (OPS) support, Network Ready, booting logo image, Local Key Operation, LG CreateBoard Share, Crestron Connected Certified, LG ConnectedCare |
| Operation Hours / Days | 16 / 7 |
| Additional Features | Picture by picture (no tuner), picture in picture (no tuner), tempered glass (4mm), 10-bit support |
| Connections | |
| Connector Type | 4 x HDMI ¦ Audio line-in ¦ LAN input ¦ LAN output ¦ HDMI output ¦ 2 x USB ¦ 2 x USB 2.0 |
| Remote Control | |
| Type | Remote control |
| Battery Included | Yes |
| Battery Included Qty | 2 |
| Battery Required Qty | 2 |
| Audio System | |
| Speaker System | 2 speakers |
| Output Power / Total | 36 watt |
| Speakers | 2 x speaker - 18 watt |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 105 in |
| Depth (Shipping) | 11 in |
| Height (Shipping) | 51.4 in |
| Weight (Shipping) | 273.26 lbs |
| Network & Internet Multimedia | |
| Connectivity | Wi-Fi, LAN, Bluetooth |
| LAN Protocol | Ethernet |
| Bluetooth Version | Bluetooth 5.3 |
| Connect & Share | Screen Share |
| Stands & Mounts | |
| VESA Compatibility | Yes |
| Media Player | |
| USB Port | Yes |
| USB Ports Qty | 4 |
| Configuration | 64 GB |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
