Cart - Constant Force lift - for LCD display / PC equipment - AC power, Tier 3, Std 1x1x2, US/CA/MX - lockable - medical - screen size: up to 27" - 45 Ah - lithium iron phosphate - TAA Compliant - for P/N: 98-668-290, 98-673-629, 98-674-290, 98-676-289, 98-678-629, 98-682-629, 98-683-629
| Main Specifications | |
|---|---|
| Product Description | Ergotron Mosaic cart - Constant Force lift - for LCD display / keyboard / mouse / CPU - AC power, Tier 3, Std 1x1x2, US/CA/MX - TAA Compliant |
| Product Type | Cart (Constant Force lift) - medical - lockable |
| Integrated Devices | Touchscreen control panel, 4-ports USB hub, 4 outlet power strip, worksurface light, document holder, 2 handles, keyboard tray, slide-out mouse tray, mouse holder, wrist rest, keyboard light, Proximity RFID reader |
| Dimensions (WxDxH) | 21.5 in x 34.7 in |
| Tilt | 0° to 35° |
| Pan | 180° |
| Lift | 25.2 in |
| Rotation | 360° |
| Adjustments | Height, tilt, pan, rotation |
| Weight | 92.59 lbs |
| Localization | United States, Canada, Mexico |
| Voltage Required | AC 120 V |
| Recommended Use | LCD display / keyboard / mouse / CPU |
| Recommended Display Size | Up to 27" |
| Battery | Lithium iron phosphate - 45 Ah |
| VESA Mounting Interface | 100 x 100 mm, 75 x 75 mm |
| Max Load Weight | 43 lbs |
| Wheels Qty | 4 |
| TAA Compliant | Yes |
| Package Content | Cable hook, power cord |
| Manufacturer Warranty | 5-year warranty |
| Designed For | P/N: 98-663-629, 98-668-290, 98-669-290, 98-670-629, 98-673-629, 98-674-290, 98-676-289, 98-678-629, 98-682-629, 98-683-629 |
| General | |
| Width | 21.5 in |
| Depth | 34.7 in |
| Weight | 92.59 lbs |
| Localization | United States, Canada, Mexico |
| Package Content | Cable hook, power cord |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - mechanical components - 5 years ¦ Limited warranty - electrical components - 5 years ¦ Limited warranty - battery defects - 5 years ¦ Limited warranty - battery performance - 3 years |
| Battery | |
| Technology | Lithium iron phosphate |
| Capacity | 45 Ah |
| Power Device | |
| Input Voltage | AC 120 V |
| AV Furniture | |
| Type | Cart - medical |
| Design | Constant Force lift |
| Recommended Use | LCD display / keyboard / mouse / CPU |
| VESA Mounting Interface | 100 x 100 mm, 75 x 75 mm |
| Integrated Devices | Touchscreen control panel, 4-ports USB hub, 4 outlet power strip, worksurface light, document holder, 2 handles, keyboard tray, slide-out mouse tray, mouse holder, wrist rest, keyboard light, Proximity RFID reader |
| Cable Management | Integrated cable management |
| Lockable | Yes |
| Recommended Display Size | Up to 27" |
| Tilt | 0° to 35° |
| Pan | 180° |
| Lift | 25.2 in |
| Rotation | 360° |
| Adjustments | Height, tilt, pan, rotation |
| Max Load Weight | 43 lbs |
| Wheels Qty | 4 |
| Wheel Diameter | 5.12 in |
| Brakes Qty | 4 |
| Lock Type | Key |
| TAA Compliant | Yes |
| Dimensions & Weight Details | |
| Shipping Dimensions (WxDxH) / Weight | 126.1 lbs |
| Compliant Standards | GSA, VESA MIS-D, ANSI/AAMI ES60601-1, CAN/CSA C22.2 No. 60601-1, FCC Part 15 A, RoHS, REACH, WEEE, Directive 94/62/EC |
| Compatibility Information | |
| Designed For | P/N: 98-663-629, 98-668-290, 98-669-290, 98-670-629, 98-673-629, 98-674-290, 98-676-289, 98-678-629, 98-682-629, 98-683-629 |
