400 Series - subwoofer - for PA system - 160 Watt - 8" - white, RAL 9003 (pack of 2)
| Main Specifications | |
|---|---|
| Product Description | JBL Professional Control 400 Series 419CS/T - subwoofer - for PA system |
| Product Type | 400 Series - subwoofer - for PA system |
| Packaged Quantity | 2 (specifications are for single item) |
| Protection | Overload protection |
| Enclosure Design | Bass reflex |
| Speaker Type | Passive |
| Speaker Diameter | 8" |
| Continuous Power | 160 watt |
| Peak Power | 640 watt |
| Nominal Impedance | 8 ohm |
| Integrated Transformer | 70V/100V or 8 Ohm operation |
| Color | White, RAL 9003 |
| Dimensions (WxDxH) | 11.4 in |
| Dimensions - Diameter | 13.6 in |
| Weight | 19.4 lbs |
| General | |
| Packaged Quantity | 2 (specifications are for single item) |
| Product Type | Subwoofer - for PA system |
| Protection | Overload protection |
| Enclosure Color | White, RAL 9003 |
| Enclosure Design | Bass reflex |
| Enclosure Material | Powder-coated steel back can, polypropylene |
| Design Features | Magnetically attached grilles, paintable grille |
| Miscellaneous | |
| Included Accessories | Backcan, C-ring, tile rails |
| Compliant Standards | IP33, UL 1480A, UL 2043, NFPA 70, NFPA 90, S7232/UL, CSA C22.2 No. 205, EN 60849, IEC 60849, IEC/EN 60529, IEC/EN 63000 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Connections | |
| Connector Type | 2 x speakers input (2-pin Euroblock) |
| Dimensions & Weight | |
| Diameter | 13.6 in |
| Height | 11.4 in |
| Weight | 19.4 lbs |
| Speaker System | |
| Series | 400 Series |
| Speaker Type | Passive |
| Speaker Diameter | 8" |
| Continuous Power | 160 watt |
| Continuous Power Details | 320 W (program) |
| Peak Power | 640 watt |
| Frequency Response (+/-3dB) | 55 - 150 Hz |
| Frequency Response (-10dB) | 47 - 320 Hz |
| Nominal Impedance | 8 ohm |
| Max Output Level (Max SPL) | 124 dB |
| Sensitivity | 96 dB |
| Integrated Transformer | 70V/100V or 8 Ohm operation |
| Coverage | 180° conical |
| Recommended Placing | In-ceiling mounted |
| Controls | Low pass filter |
| Detachable Grilles | Yes |
| Speaker System Details | |
| Driver Details | Subwoofer: subwoofer driver - 8" - paper - cone |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 55.71 lbs |
| Cutout & Mounting Dimensions | |
| Diameter | 12.1 in |
