ICD Series LED video wall - cinema - 4096 x 2160 227" 128 x 60 (LED unit) / 512 x 720 (cabinet) per unit - 3-in-1 1010 - HDR
| Main Specifications | |
|---|---|
| Product Description | Samsung Onyx Cinema IC012D ICD Series LED video wall - for cinema |
| Product Type | LED video wall |
| Diagonal Size | 227" |
| Commercial Use | Yes - cinema |
| Video Wall Resolution | 4096 x 2160 |
| Frame Rate & Enhancement Technology | 3840 Hz Refresh Rate, 120 Hz IMB Frame Rate |
| TV Tuner | No tuner |
| Commercial Features | Dolby Media Server compatible, GDC Media Server compatible |
| Picture Enhancements | True Black, Vivid Color Expression, Distortion-free |
| Video Wall Display Unit | 3-in-1 1010 - 128 x 60 (LED unit) / 512 x 720 (cabinet) |
| Voltage | AC 100 -240 V |
| General | |
| Product Type | LED video wall |
| Commercial Use | Yes - cinema |
| Series | ICD Series |
| HDR Capable | Yes |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Picture Enhancements | True Black, Vivid Color Expression, Distortion-free |
| Miscellaneous | |
| Compliant Standards | DCI (Digital Cinema Initiatives), IP20 |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100 -240 V |
| Video Wall Display Unit Power Consumption (Max) | 345.1 W |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 80 % RH |
| Display | |
| Frame Rate & Enhancement Technology | 3840 Hz Refresh Rate, 120 Hz IMB Frame Rate |
| Brightness | 300 cd/m² |
| Viewing Angle | 160° |
| Viewing Angle (Vertical) | 160° |
| Commercial Features | Dolby Media Server compatible, GDC Media Server compatible |
| Additional Features | 90% brightness uniformity |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 25.2 in |
| Depth (Shipping) | 4.9 in |
| Height (Shipping) | 35.4 in |
| Weight (Shipping) | 41.01 lbs |
| Video Wall Display Unit | |
| Pixel Pitch | 1.25 mm |
| LED Type | 3-in-1 1010 |
| Aspect Ratio | 1.85:1/2.39:1 |
| Resolution | 128 x 60 (LED unit) / 512 x 720 (cabinet) |
| Maintenance | Rear |
| Video Wall | |
| Resolution | 4096 x 2160 |
| Diagonal Size | 227" |
