Switch - half-width - L3 - managed - 18 x 1/10/25 Gigabit SFP28 + 4 x 40 Gigabit / 100 Gigabit QSFP28 - back to front airflow - rack-mountable
| Main Specifications | |
|---|---|
| Product Description | HPE Aruba Networking CX 8325H 18p SFP28 25G 4p QSFP28 100G Switch - switch - half-width - 18 ports - managed - rack-mountable |
| Device Type | Switch - 18 ports - L3 - managed |
| Enclosure Type | Back to front airflow rack-mountable 1U |
| Subtype | 25 Gigabit Ethernet |
| Ports | 18 x 1/10/25 Gigabit SFP28 + 4 x 40 Gigabit / 100 Gigabit QSFP28 |
| Performance | Switching capacity: 6.4 Tbps ¦ Throughput: 2000 Mpps |
| Capacity | Packet buffer size: 32 MB |
| Jumbo Frame Support | 9KB |
| Routing Protocol | OSPF, BGP, BGP-4, EGP, VRRP, MLD, ECMP, PIM-SM, GRE, static IP routing, IGMP, IGMPv2, IGMPv3, OSPFv3, static IPv6 routing, policy-based routing (PBR), MSTP, RSTP, STP |
| Remote Management Protocol | SNMP, RMON, SNMP 3, SNMP 2c, TFTP, SFTP, SSH, CLI, NTP |
| Features | OSPF, policy based routing, STP support, RSTP support, MSTP support, QoS, Jumbo Frames support, MLD snooping, sFlow, ACL support, IPv4 support, IPv6 support, LACP, UDLD, SP, DWRR, PIM, VTEP support, ToR, EoR |
| Compliant Standards | IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.1t, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3ba, IEEE 802.1AX, IEEE 802.3x |
| Power Redundancy | Yes |
| Manufacturer Warranty | Limited lifetime warranty |
| General | |
| Device Type | Switch - 18 ports - L3 - managed |
| Enclosure Type | Back to front airflow rack-mountable 1U |
| Subtype | 25 Gigabit Ethernet |
| Ports | 18 x 1/10/25 Gigabit SFP28 + 4 x 40 Gigabit / 100 Gigabit QSFP28 |
| Performance | Switching capacity: 6.4 Tbps ¦ Throughput: 2000 Mpps |
| Capacity | Packet buffer size: 32 MB |
| Jumbo Frame Support | 9KB |
| Routing Protocol | OSPF, BGP, BGP-4, EGP, VRRP, MLD, ECMP, PIM-SM, GRE, static IP routing, IGMP, IGMPv2, IGMPv3, OSPFv3, static IPv6 routing, policy-based routing (PBR), MSTP, RSTP, STP |
| Remote Management Protocol | SNMP, RMON, SNMP 3, SNMP 2c, TFTP, SFTP, SSH, CLI, NTP |
| Authentication Method | RADIUS, TACACS+, Secure Shell (SSH), Secure Shell v.2 (SSH2) |
| Features | OSPF, policy based routing, STP support, RSTP support, MSTP support, QoS, Jumbo Frames support, MLD snooping, sFlow, ACL support, IPv4 support, IPv6 support, LACP, UDLD, SP, DWRR, PIM, VTEP support, ToR, EoR |
| Compliant Standards | IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.1t, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3ba, IEEE 802.1AX, IEEE 802.3x |
| Processor | 1 x AMD |
| RAM | 32 GB |
| Built-in Devices | 128 GB SSD, 4 x fans |
| Expansion / Connectivity | |
| Interfaces | 18 x 1/10/25Gbit LAN SFP28 ¦ 4 x 100Gbit/40Gbit LAN QSFP28 ¦ 1 x console RJ-45 ¦ 1 x USB Type A AUX ¦ 1 x management RJ-45 ¦ 1 x console USB Type-C |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Power | |
| Power Device | Internal power supply |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
