MMF Series LED display unit - digital signage 27.1" 384 x 216 per unit - Flip-chip RGB LED - HDR
| Main Specifications | |
|---|---|
| Product Description | Samsung The Wall MM015F MMF Series LED display unit - for digital signage |
| Product Type | LED display unit |
| Commercial Use | Yes - digital signage |
| HDR Format | HDR10, HDR10+ |
| Frame Rate & Enhancement Technology | 60 Hz Video Rate, 50 Hz Video Rate, 3840 Hz Frame Rate |
| TV Tuner | No tuner |
| Picture Enhancements | AI Picture, True Black |
| Video Wall Display Unit | 27.1" - Flip-chip RGB LED - 384 x 216 |
| Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Stand by | 0.5 watt |
| Dimensions (WxDxH) - display units assembly | 23.6 in x 2 in x 13.3 in |
| Weight | 11.24 lbs |
| General | |
| Product Type | LED display unit |
| Commercial Use | Yes - digital signage |
| Series | MMF Series |
| HDR Capable | Yes |
| HDR Format | HDR10, HDR10+ |
| Video Processor | NQM AI |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Sensors | Temperature sensor |
| Picture Enhancements | AI Picture, True Black |
| Dimensions | Display units assembly |
| Width | 23.6 in |
| Depth | 2 in |
| Height | 13.3 in |
| Weight | 11.24 lbs |
| Miscellaneous | |
| Compliant Standards | TUV Eye Comfort certified, Safety 62368-1, Safety 60950-1, EMC Class A |
| Power | |
| Power Device | Power adapter |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Stand by | 0.5 watt |
| Video Wall Display Unit Power Consumption (Max) | 94.6 W |
| Video Wall Display Unit Power Consumption (Typical) | 37 W |
| Video Wall Power Consumption (Max) | 467.2 W/m² |
| Video Wall Power Consumption (Typical) | 183 W/m² |
| Heat Generation Details | Cabinet - max - 1593.9 BTU/m² ¦ Cabinet - max - 322.8 BTU ¦ Cabinet - typical - 626 BTU/m² ¦ Cabinet - typical - 127 BTU |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 80% RH |
| Display | |
| Frame Rate & Enhancement Technology | 60 Hz Video Rate, 50 Hz Video Rate, 3840 Hz Frame Rate |
| Color Temperature | 6500K |
| Brightness | 600 cd/m² |
| Viewing Angle | 160° |
| Viewing Angle (Vertical) | 160° |
| Additional Features | MagicInfo, 20-bit processing, 16-bit support |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 26.8 in |
| Depth (Shipping) | 5.5 in |
| Height (Shipping) | 16.1 in |
| Weight (Shipping) | 15.21 lbs |
| Video Wall Display Unit | |
| Pixel Pitch | 1.56 mm |
| Pixel Configuration | 1 red, 1 green, 1 blue |
| LED Type | Flip-chip RGB LED |
| Resolution | 384 x 216 |
| Maintenance | Front |
| Cabinet Diagonal Size | 27.1" |
| Modules Configuration (Per Cabinet) | 4x2 |
