Copilot+ PC - mini PC Core Ultra 7 226V / up to 4.5 GHz - RAM 16 GB - SSD 512 GB - NVMe - Arc Graphics 130V - 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7) - Win 11 - monitor: none - black
| Main Specifications | |
|---|---|
| Product Description | ASUS NUC 14 Pro AI RNUC14LNKU5078HU - mini PC - Copilot+ PC - Core Ultra 7 226V 2.1 GHz - 16 GB - SSD 512 GB |
| Type | Personal computer - mini PC - Copilot+ PC |
| Processor | Intel Core Ultra 7 (Series 2) 226V / 2.1 GHz (up to 4.5 GHz, (8-core) |
| Processor Main Features | Intel Smart Cache |
| Neural Processor Unit (NPU) | Intel AI Boost - up to 40 TOPS |
| Cache Memory | 8 MB |
| Cache Per Processor | 8 MB |
| RAM | 16 GB LPDDR5X SDRAM |
| Storage Controller | SATA (SATA 6Gb/s) |
| Hard Drive | SSD 512 GB - PCI Express 4.0 (NVMe) - M.2 2280 - NVM Express (NVMe) |
| Optical Storage | No optical drive |
| Graphics Controller | Intel Arc Graphics 130V |
| Networking | 802.11a, 802.11b/g/n, Wi-Fi 5, 2.5GbE, Wi-Fi 6, Bluetooth, Wi-Fi 7 |
| OS Provided | Windows 11 |
| Color | Black |
| Dimensions (WxDxH) | 5.1 in x 5.1 in x 1.3 in |
| Weight | 17.64 oz |
| Environmental Standards | EPEAT Gold |
| Manufacturer Warranty | Limited warranty - 3 years |
| General | |
| Type | Personal computer |
| AI Level | Copilot+ PC |
| Product Form Factor | Mini PC |
| Built-in Devices | Fingerprint reader |
| Embedded Security | Trusted Platform Module (TPM) Security Chip |
| Color | Black |
| Expansion / Connectivity | |
| Interfaces | 2 x USB 3.2 Gen 2 ¦ 2 x Thunderbolt 4 ¦ 1 x HDMI ¦ 1 x LAN (2.5Gigabit Ethernet) ¦ 2 x USB 3.2 Gen 1 ¦ 1 x headphones/microphone - mini-jack |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| RAM | |
| Installed Size | 16 GB |
| Technology | LPDDR5X SDRAM |
| Effective Memory Speed | 8533 MT/s |
| Rated Memory Speed | 8533 MT/s |
| Networking | |
| Ethernet Controller | Intel I226-V |
| Wireless LAN Supported | Yes |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7) |
| Power | |
| Device Type | Power adapter |
| Storage Controller | |
| Type | SATA |
| Controller Interface Type | SATA 6Gb/s |
| Channel Qty | 1 |
| Cache Memory | |
| Installed Size | 8 MB |
| Cache Per Processor | 8 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel Arc Graphics 130V |
| Video Interfaces | HDMI |
| Operating System / Software | |
| OS Provided | Windows 11 |
| Hard Drive | |
| Type | SSD - M.2 2280 |
| Capacity | 1 x 512 GB |
| Interface Type | PCI Express 4.0 (NVMe) |
| Features | NVM Express (NVMe) |
| Dimensions & Weight | |
| Width | 5.1 in |
| Depth | 5.1 in |
| Height | 1.3 in |
| Weight | 17.64 oz |
| Processor / Chipset | |
| CPU | Intel Core Ultra 7 (Series 2) 226V |
| Clock Speed | 2.1 GHz (P-core) / 2.1 GHz (E-core) |
| Max Turbo Speed | 4.5 GHz (P-core) / 3.5 GHz (E-core) |
| Number of Cores | 8-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Processor Main Features | Intel Smart Cache |
| Sustainability Information | |
| EPEAT Compliant | EPEAT Gold |
| Neural Processor Unit (NPU) | |
| Neural Processor Unit (NPU) | Intel AI Boost |
| NPU Performance Up To (TOPS) | 40 TOPS |
| Sparsity Support | Yes |
| AI Software Frameworks Supported by NPU | DirectML, OpenVINO, WebNN, WindowsML, ONNX RT |
| Windows Studio Effects Support | Yes |
