DLP projector - laser/phosphor - 3D - 10700 ANSI lumens - 2716 x 1600 - 17:10 - standard lens
| Main Specifications | |
|---|---|
| Product Description | Barco F80-Q12 - DLP projector - standard lens - 3D |
| Device Type | DLP projector |
| 3D Capable | Yes (3D glasses sold separately) |
| Built-in Devices | Status LCD, keypad |
| Microdisplay | DLP Chip |
| Brightness | 10700 ANSI lumens |
| Contrast Ratio | 1200:1 / 10000:1 (dynamic) |
| Resolution | 2716 x 1600 |
| Native Aspect Ratio | 17:10 |
| Lens | Standard lens |
| Lamp Type | Laser/phosphor |
| Lamp Life Cycle | Up to 20000 hour(s) - normal mode ¦ Up to 12000 hour(s) - silent mode ¦ Up to 40000 hour(s) - long life mode ¦ Up to 12000 hour(s) - bright mode |
| Video Modes | 4K |
| Power | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 1050 Watt |
| Dimensions (WxDxH) | 18.9 in x 26.8 in x 8.9 in |
| Weight | 59.08 lbs |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | DLP projector |
| 3D Capable | Yes (3D glasses sold separately) |
| Built-in Devices | Status LCD, keypad |
| Networking | Ethernet |
| Expansion / Connectivity | |
| Interfaces | 1 x HDMI input - 19 pin HDMI Type A ¦ 2 x DVI-D (dual link) - DVI-D ¦ 2 x DisplayPort - 20 pin DisplayPort (1.2) ¦ 1 x network - RJ-45 ¦ 2 x USB 2.0 - 4 pin USB Type A ¦ 1 x serial RS-232 - 9 pin D-Sub (DB-9) ¦ 2 x 12V programmable trigger ¦ 1 x HDBaseT input - RJ-45 ¦ 1 x DMX input ¦ 1 x DMX output ¦ 2 x 12G-SDI - BNC ¦ 2 x Sync - BNC ¦ 1 x 3D Sync out - mini-DIN ¦ 1 x remote control - mini-phone 3.5 mm |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years |
| Miscellaneous | |
| Included Accessories | Wireless remote control |
| Compliant Standards | EN 55022 Class A, EN 60950-1, FCC Part 15 A, UL 60950-1, RoHS |
| Power | |
| Power Source | AC |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 1050 Watt |
| Power Consumption Stand by | 0.5 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 0 - 80% |
| Sound Emission | 39 dBA |
| Sound Emission (Economic Mode) | 35 dBA |
| Video Input | |
| Video Interfaces | 12G-SDI, DisplayPort, DVI, HDBaseT, HDMI |
| Video Modes | 4K |
| Dimensions & Weight | |
| Width | 18.9 in |
| Depth | 26.8 in |
| Height | 8.9 in |
| Weight | 59.08 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 23 in |
| Shipping Depth | 30.9 in |
| Shipping Height | 17.5 in |
| Shipping Weight | 84.88 lbs |
| Projector | |
| Microdisplay | DLP Chip |
| Brightness | 10700 ANSI lumens |
| Contrast Ratio | 1200:1 / 10000:1 (dynamic) |
| Throw Ratio | 1.43 - 2.12:1 |
| Uniformity | 90 % |
| Resolution | WQXGA+ - 2716 x 1600 (native) / 3840 x 2400 (resized) |
| Native Aspect Ratio | 17:10 |
| Max Sync Rate (V x H) | 120 Hz |
| Lamp Type | Laser/phosphor |
| Lamp Life Cycle | Up to 20000 hour(s) - normal mode ¦ Up to 12000 hour(s) - silent mode ¦ Up to 40000 hour(s) - long life mode ¦ Up to 12000 hour(s) - bright mode |
| Controls & Adjustments | Keystone correction |
| Features | RealColor, Constant Light Output (CLO), sealed DLP core, DLP 3D Ready, embedded warp and blend, 24/7 operation, HDR10 compatibility, Active Stereo 3D, Rec. 709 Mode, PJlink, Edge blending, integrated web browser |
| Lens | |
| Type | Standard lens |
| Focus Type | Powered |
| Zoom Type | Powered |
| Lens Shift Type | Powered |
