Application accelerator - 10GbE - 2U - 4 nodes - rack-mountable
| Main Specifications | |
|---|---|
| Product Description | Nutanix Xtreme Computing Platform NX-3460-G9 - application accelerator |
| Device Type | Application accelerator |
| Form Factor | Rack-mountable - 2U |
| Processor | 2 x Intel Xeon Silver 4510 - 2.4 GHz |
| RAM | 1536 GB (max) |
| Data Link Protocol | 10 Gigabit Ethernet |
| Pricing Type | 4 nodes |
| Environmental Standards | ENERGY STAR Qualified |
| Dimensions (WxDxH) | 17.8 in x 30.6 in x 3.5 in |
| Weight | 86.86 lbs |
| General | |
| Device Type | Application accelerator |
| Height (Rack Units) | 2U |
| Built-in Devices | 2 x 512 GB M.2 boot drives, 8 x 80 mm fans |
| Width | 17.8 in |
| Depth | 30.6 in |
| Height | 3.5 in |
| Weight | 86.86 lbs |
| Expansion / Connectivity | |
| Expansion Bays | 6 (total) / 6 (free) x hot-swap |
| Expansion Slots | 2 (total) / 2 (free) x expansion slot |
| Interfaces | 1 x IPMI - RJ-45 ¦ 2 x 10GBase-T - RJ-45 ¦ 1 x VGA ¦ 2 x USB 3.0 - Type A |
| Miscellaneous | |
| Compliant Standards | BIS, BSMI, CSA, CSAus, EAC, FCC, ICES, KCC, RCM, REACH, RoHS, S Mark, SABS, SII, UKCA, UkrSEPRO, UL, VCCI-A, WEEE, cUL |
| Pricing Type | 4 nodes |
| Networking | |
| Form Factor | Rack-mountable |
| Connectivity Technology | Wired |
| Data Link Protocol | 10 Gigabit Ethernet |
| Features | 12-core CPU, UID button |
| Power | |
| Power Device | Internal power supply |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Power Provided | 3000 Watt |
| 80 PLUS Certification | 80 PLUS Titanium |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 77 °F |
| Humidity Range Operating | 8 - 90% |
| Processor / Memory / Storage | |
| Processors Installed | 2 x Intel Xeon Silver 4510 2.4 GHz |
| Max Supported Qty | 2 |
| RAM | (1536 GB max) |
| Environmental Standards | |
| ENERGY STAR Certified | Yes |
