Palm size Core i5 8365UE / up to 4.1 GHz - vPro - RAM 16 GB - no HDD - UHD Graphics 620 - no OS - monitor: none
| Main Specifications | |
|---|---|
| Product Description | Advantech EPC-U3233 - palm size Core i5 8365UE 1.6 GHz - vPro - 16 GB - no HDD |
| Type | Personal computer - palm size |
| Platform Technology | Intel vPro Platform |
| Processor | Intel Core i5 (8th Gen) 8365UE / 1.6 GHz (up to 4.1 GHz, (Quad-Core) |
| Cache Memory | 6 MB |
| Cache Per Processor | 6 MB |
| RAM | 16 GB (installed) / 16 GB (max) - DDR4 SDRAM |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Graphics Controller | Intel UHD Graphics 620 |
| Power | AC 120/230 V |
| OS Provided | No operating system |
| Dimensions (WxDxH) | 6.7 in x 4.6 in x 2.6 in |
| Weight | 4.19 lbs |
| General | |
| Platform Technology | Intel vPro Platform |
| Type | Personal computer |
| Product Form Factor | Palm size |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Expansion / Connectivity | |
| Slots | 1 (total) / 1 (free) x M.2 Card - 2280 (Key M) ¦ 1 (total) / 1 (free) x M.2 Card - 2242/3042 (Key B) ¦ 1 (total) / 1 (free) x M.2 Card - 2230 (Key E) ¦ 1 (total) / 1 (free) x Nano-SIM card |
| Interfaces | 1 x audio line-out (1 rear) ¦ 2 x HDMI (2 rear) ¦ 2 x USB 3.0 - Type A (2 front) ¦ 2 x USB 2.0 - Type A (2 side) ¦ 4 x serial (RS-232) (2 front, 2 side) ¦ 2 x serial (RS-232/422/485) (1 rear, 1 side) ¦ 2 x LAN (Gigabit Ethernet) - RJ-45 (2 rear) ¦ 2 x GPIO (2 rear) |
| Miscellaneous | |
| Included Accessories | Wall mounting kit |
| Compliant Standards | FCC, CB, UL, CCC, BSMI |
| RAM | |
| Installed Size | 16 GB (installed) / 16 GB (max) |
| Technology | DDR4 SDRAM |
| Effective Memory Speed | 1200 MHz |
| Rated Memory Speed | 1200 MHz |
| Form Factor | SO-DIMM 260-pin |
| Slots | 1 (total) / 0 (empty) |
| Configuration Features | 1 x 16 GB |
| Power | |
| Device Type | No power adapter |
| Voltage Required | AC 120/230 V |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Cache Memory | |
| Installed Size | 6 MB |
| Cache Per Processor | 6 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel UHD Graphics 620 |
| Video Interfaces | HDMI |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Operating System / Software | |
| OS Provided | No operating system |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 6.7 in |
| Depth | 4.6 in |
| Height | 2.6 in |
| Weight | 4.19 lbs |
| Processor / Chipset | |
| CPU | Intel Core i5 (8th Gen) 8365UE |
| Clock Speed | 1.6 GHz |
| Max Turbo Speed | 4.1 GHz |
| Number of Cores | Quad-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
