AI PC - Intel Core Ultra 9 - 185H / up to 5.1 GHz - Win 11 Pro - GeForce RTX 4070 - 32 GB RAM - 1 TB SSD NVMe - 16.28" OLED touchscreen 3840 x 2400 (UHD+) @ 90 Hz - Wi-Fi 7 - platinum - BTS - with 1 Year Basic Onsite Service after remote diagnosis with Hardware-Only Support - Disti SnS
| Main Specifications | |
|---|---|
| Product Description | Dell XPS 16 9640 - AI PC - 16.28" - Intel Core Ultra 9 - 185H - 32 GB RAM - 1 TB SSD |
| Product Type | Notebook - AI PC |
| Operating System | Win 11 Pro - English / French / Spanish |
| Processor | Intel Core Ultra 9 (Series 1) - 185H / 2.3 GHz, up to 5.1 GHz / 24 MB Cache |
| Neural Processor Unit (NPU) | Intel AI Boost |
| Memory | 32 GB LPDDR5X SDRAM (provided memory is soldered) |
| Storage | 1 TB SSD - NVMe |
| Display | 16.28" OLED touchscreen 3840 x 2400 / UHD+ @ 90 Hz - 278.1 ppi |
| Graphics | NVIDIA GeForce RTX 4070 |
| Video Memory | 8 GB GDDR6 SDRAM |
| Keyboard Backlight | Yes |
| Integrated Webcam | Yes |
| Networking | Bluetooth, 802.11a/b/g/n/ac/ax/be |
| Battery | 6-cell |
| Features | Accelerometer, ambient light sensor |
| Security | Trusted Platform Module (TPM 2.0) Security Chip, fingerprint reader |
| Color | Platinum |
| Dimensions (WxDxH) | 14.1 in x 9.5 in x 0.7 in |
| Weight | 4.81 lbs |
| Pricing Type | Build To Stock (BTS) |
| Carbon Footprint | 363 kg carbon emissions |
| Specific Absorption Rate (SAR) | 1.431 W/kg (body) ¦ 1.431 W/kg (limb) |
| Bundled Services | 1 Year Basic Onsite Service after remote diagnosis with Hardware-Only Support - Disti SnS |
| General | |
| Product Type | Notebook |
| AI Level | AI PC |
| Operating System | Windows 11 Pro - English / French / Spanish |
| Memory | |
| RAM | 32 GB (provided memory is soldered) |
| Technology | LPDDR5X SDRAM |
| Speed | 3733.5 MHz |
| Rated Speed | 3733.5 MHz |
| Manufacturer Warranty | |
| Bundled Services | 1 Year Basic Onsite Service after remote diagnosis with Hardware-Only Support - Disti SnS |
| Miscellaneous | |
| Color | Platinum |
| Integrated Options | Accelerometer, ambient light sensor |
| Security | Trusted Platform Module (TPM 2.0) Security Chip, fingerprint reader |
| Features | ExpressCharge, GPU max power 60 Watts |
| Included Accessories | USB-C power adapter |
| Compliant Standards | FIPS 140-2, TCG Certified |
| Specific Absorption Rate (SAR) | 1.431 W/kg (body) ¦ 1.431 W/kg (limb) |
| Pricing Type | Build To Stock (BTS) |
| Storage | |
| Main Storage | 1 TB SSD M.2 PCIe 4.0 x4 - NVM Express (NVMe) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Shock Tolerance (operating) | 110 g @ 2 ms half-sine pulse |
| Shock Tolerance (non-operating) | 160 g @ 2 ms half-sine pulse |
| Vibration Tolerance (operating) | 0.66 g @ RMS (random) |
| Vibration Tolerance (non-operating) | 1.3 g @ RMS (random) |
| Software | |
| Software Included | McAfee Business Protection (1-year), Dell Additional Softwares, Activate your Microsoft 365 for a 30 day trial |
| Battery | |
| Technology | 6-cell lithium polymer |
| Weight | 380 g |
| Capacity | 99.5 Wh |
| Display | |
| Type | 16.28" OLED |
| Touchscreen | Yes |
| Resolution | 3840 x 2400 (UHD+) |
| V-Sync Rate at Max Res. | 90 Hz |
| Widescreen | Yes |
| Pixel Density (ppi) | 278.1 |
| Image Brightness | 400 cd/m² |
| Horizontal Viewing Angle | +89 / -89 |
| Vertical Viewing Angle | +89 / -89 |
| Color Gamut | 100% DCI-P3 |
| Features | Anti-reflective, anti-smudge, Infinity Edge display, Wide Viewing Angle, 0.09 mm pixel pitch, Eyesafe technology, 1 ms response rate, 2 ms response rate |
| Communications | |
| Wireless | Bluetooth, 802.11a/b/g/n/ac/ax/be |
| Wireless Controller | Intel WI-FI 7 BE200 |
| Features | Dual stream (2x2) |
| Dimensions & Weight | |
| Dimensions (WxDxH) | 14.1 in x 9.5 in x 0.7 in |
| Weight | 4.81 lbs |
| Processor / Chipset | |
| CPU | Intel Core Ultra 9 (Series 1) 185H / 2.3 GHz |
| Max Turbo Speed | 5.1 GHz |
| Number of Cores | 16-core |
| Cache | 24 MB |
| Audio & Video | |
| Graphics Processor | NVIDIA GeForce RTX 4070 |
| Video Memory | 8 GB GDDR6 SDRAM |
| Camera | Yes - 1920 x 1080 (standard), 640 x 360 (infrared) |
| Resolution | 2.07 Megapixel (standard), 0.23 Megapixel (infrared) |
| Image Sensor Type | CMOS |
| Video Resolutions | 1920 x 1080, 640 x 360 |
| Frame Rate | 30 frames per second |
| Camera Features | IR camera, Windows Hello, RGB camera, 81.3 degrees, 78.1 degrees (IR camera) |
| Sound | Two tweeters, two woofers, 2 array microphones |
| Codec | CS42L43 |
| Input | |
| Type | Keyboard, touchpad |
| Keyboard Backlight | Yes |
| AC Adapter | |
| Input | AC 100-240 V (50/60 Hz) |
| Output | 130 watt, 5 / 9 / 15 / 20 V |
| Connections & Expansion | |
| Interfaces Details | 2 x USB4 (supports Thunderbolt 4, DisplayPort 2.1 Alt Mode) (Power Delivery) ¦ USB-C 3.2 Gen 2 (supports DisplayPort 1.4 Alt Mode) (Power Delivery) ¦ Headphone/microphone combo jack |
| Memory Card Reader | Yes (microSD, microSDHC, microSDXC) |
| Sustainability Information | |
| Carbon Footprint | 363 kg carbon emissions |
| Total CF/unit Standard Deviation (kg CO2e) | 62 |
| Manufacturing (kg CO2e) | 296.57 |
| Logistics (kg CO2e) | 18.959 |
| Use (kg CO2e) | 45.52 |
| EOL (kg CO2e) | 2.4 |
| Total Carbon w/o Use Phase (kg CO2e) | 317.48 |
| PAIA Version | 1.4.0, 2024 |
| Neural Processor Unit (NPU) | |
| Neural Processor Unit (NPU) | Intel AI Boost |
| Sparsity Support | Yes |
| AI Software Frameworks Supported by NPU | DirectML, OpenVINO, WindowsML, ONNX RT |
| Windows Studio Effects Support | Yes |
