UPS (rack-mountable / external) - extended runtime, hardwired 3-wire output, network card, with rail kit - AC 208 V - 4900 Watt - 5000 VA - 1-phase - lithium ion - USB - output connectors: 1 - 2U - silver gray - for P/N: SRTL180RM2UBP
| Main Specifications | |
|---|---|
| Product Description | APC Smart-UPS Ultra On-Line - UPS - extended runtime, hardwired 3-wire output, network card, with rail kit - 4900 watt - 5000 VA - Li-Ion |
| Device Type | UPS - rack-mountable / external |
| Rack Size | 2U |
| Weight | 64.37 lbs |
| Input Wiring | 1-phase |
| Input Voltage | AC 208 V |
| Output Voltage | AC 208 V |
| Power Capacity | 4900 watt / 5000 VA |
| Input Connectors | 1 x power NEMA L6-30P |
| Output connectors | 1 x hardwire 3-wire (1PH + N + G) |
| Battery | Lithium ion expandable lithium ion |
| Batteries Qty | 1 |
| Run Time (Up To) | 5.35 min at full load |
| Networking | USB |
| Included Accessories | Temperature sensor, stabilization feet, front cover, earth terminal block, rail extension |
| Color | Silver gray |
| Packaging Recycled Content | Made of recycled cardboard |
| Dimensions (WxDxH) | 17 in x 27.6 in x 3.4 in |
| Environmental Standards | ENERGY STAR |
| Manufacturer Warranty | 5-year warranty |
| Designed For | P/N: SRTL180RM2UBP |
| General | |
| Device Type | UPS - rack-mountable / external |
| Height (Rack Units) | 2U |
| Color | Silver gray |
| Expansion / Connectivity | |
| Interfaces | 1 x EPO (emergency power off) ¦ Management (USB) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Included Accessories | Temperature sensor, stabilization feet, front cover, earth terminal block, rail extension |
| Cables Included | USB cable - external ¦ Network cable - external |
| Rack Mounting Kit | Included |
| Features | Horizontal orientation, user-replaceable removable battery, audible alarm, emergency power off, LCD display, internal bypass, visible alarm, Auto-Sensing Technology, double conversion |
| Compliant Standards | REACH, IEC 62040-1, EN 62040-1, EU RoHS, UKCA |
| Networking | |
| Remote Management Interface | USB |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Sound Emission | 55 dBA |
| Battery | |
| Type | Expandable |
| Quantity | 1 |
| Technology | Lithium ion lithium ion |
| Voltage Provided | 180 V |
| Recharge Time | 1.5 hours |
| Power Device | |
| UPS Technology | On-line |
| Input Voltage | AC 208 V |
| Frequency Provided | 50/60 Hz |
| Input Wiring | 1-phase |
| Input Connectors | 1 x power NEMA L6-30P |
| Power Output Connectors Details | 1 x hardwire 3-wire (1PH + N + G) |
| Output Voltage | AC 208 V 50/60 Hz |
| Power Capacity | 4900 watt / 5000 VA |
| Output Waveform | Sinewave |
| Surge Suppression | Yes |
| Surge Energy Rating | 1260 joules |
| Dimensions & Weight | |
| Width | 17 in |
| Depth | 27.6 in |
| Height | 3.4 in |
| Weight | 64.37 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 23 in |
| Shipping Depth | 38.7 in |
| Shipping Height | 15.4 in |
| Shipping Weight | 84.88 lbs |
| Compatibility Information | |
| Designed For | P/N: SRTL180RM2UBP |
| Sustainability Information | |
| ENERGY STAR | Yes |
| Packaging Recycled Content | Made of recycled cardboard |
