Wireless access point - Wi-Fi 5 - 2.4 GHz, 5 GHz - wall mountable
| Main Specifications | |
|---|---|
| Product Description | Grandstream GWN Series GWN7603 - wireless access point - Wi-Fi 5 |
| Device Type | Wireless access point |
| Form Factor | Wall mountable - indoor |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2 |
| Frequency Band | 2.4 GHz, 5 GHz |
| Performance | Maximum data rate (2.4 GHz): 400 Mbps ¦ Maximum data rate (5 GHz): 867 Mbps ¦ Channel bandwidth (5 GHz): 20 / 40 / 80 MHz ¦ Channel bandwidth (2.4 GHz): 20 / 40 MHz |
| Capacity | Number of concurrent clients: up to 100 ¦ SSIDs per radio: 8 ¦ SSIDs total: 16 |
| Included Accessories | Wall mounting kit |
| Power Over Ethernet (PoE) Supported | PoE+ |
| Dimensions (WxDxH) | 5.3 in x 4.5 in x 1.2 in |
| Weight | 7.58 oz |
| General | |
| Device Type | Wireless access point |
| Ruggedized Design | Indoor |
| Width | 5.3 in |
| Depth | 4.5 in |
| Height | 1.2 in |
| Weight | 7.58 oz |
| Expansion / Connectivity | |
| Interfaces | 1 x 1000Base-T (uplink, PoE+ input) - RJ-45 ¦ 1 x 10/100/1000Base-T - RJ-45 ¦ 2 x 10/100/1000Base-T (PoE) - RJ-45 |
| Miscellaneous | |
| Included Accessories | Wall mounting kit |
| Compliant Standards | FCC, IC, RCM |
| Networking | |
| Form Factor | Wall mountable |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 1.27 Gbps |
| Line Coding Format | 256 QAM |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2 |
| Network / Transport Protocol | IPv6, IPv4 |
| Frequency Band | 2.4 GHz, 5 GHz |
| Max Range Open Space | 328 ft |
| Performance | Maximum data rate (2.4 GHz): 400 Mbps ¦ Maximum data rate (5 GHz): 867 Mbps ¦ Channel bandwidth (5 GHz): 20 / 40 / 80 MHz ¦ Channel bandwidth (2.4 GHz): 20 / 40 MHz |
| Capacity | Number of concurrent clients: up to 100 ¦ SSIDs per radio: 8 ¦ SSIDs total: 16 |
| Features | 2x2:2 MU-MIMO technology, secure boot, Advanced QoS, Port-side exhaust (PSE), reset button, security slot (Kensington security lock compatible), LED status indicator, Wi-Fi Multimedia (WMM) support, VLAN support, Type of Service (ToS), 12W PoE power budget |
| Encryption Algorithm | WEP, WPA2-PSK, WPA-PSK, WPA2-Enterprise, WPA-Enterprise, TKIP, AES, WPA3 |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.11e, IEEE 802.3af, IEEE 802.3at |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE+ |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 6.7 in |
| Shipping Depth | 5.5 in |
| Shipping Height | 1.3 in |
| Shipping Weight | 10.4 oz |
| Antenna | |
| Antenna | Internal |
| Antenna Qty | 2 |
