DR-Series - LED monitor - 22" (21.5" viewable) - mountable / desktop - 1920 x 1080 Full HD (1080p) - IPS - 500 cd/m² - 1000:1 - 5 ms - HDMI, VGA, DisplayPort - speakers
| Main Specifications | |
|---|---|
| Product Description | AG Neovo DR-2202 - DR-Series - LED monitor - Full HD (1080p) - 22" |
| Device Type | LED-backlit LCD monitor - 22" |
| Panel Type | IPS |
| Native Resolution | Full HD (1080p) 1920 x 1080 |
| Pixel Pitch | 0.248 mm |
| Brightness | 500 cd/m² |
| Contrast Ratio | 1000:1 |
| Response Time | 5 ms |
| Color Support | 16.7 million colors |
| Input Connectors | HDMI, VGA, DisplayPort |
| Screen Coating | Anti-glare, 3H Hard Coating, Haze 25% |
| Dimensions (WxDxH) - without base | 20.8 in x 1.9 in x 12.8 in |
| Weight | 10.36 lbs |
| Compliant Standards | FCC, RoHS, WEEE, DICOM Part 14, REACH, LVD, EAC, IEC/EN 60601-1, IEC/EN 60601-1-2, ICES-003 issue 7 |
| General | |
| Display Type | LED-backlit LCD monitor / TFT active matrix |
| Diagonal Size | 22" |
| Viewable Size | 21.5" |
| Panel Type | IPS |
| Native Resolution | Full HD (1080p) 1920 x 1080 |
| Pixel Pitch | 0.248 mm |
| Brightness | 500 cd/m² |
| Contrast Ratio | 1000:1 |
| Color Support | 16.7 million colors |
| Response Time | 5 ms |
| Vertical Refresh Rate | 56 - 75 Hz |
| Horizontal Refresh Rate | 31 - 84 kHz |
| Horizontal Viewing Angle | 178 |
| Vertical Viewing Angle | 178 |
| Screen Coating | Anti-glare, 3H Hard Coating, Haze 25% |
| Backlight Technology | LED backlight |
| Features | NeoV Optical Glass, Wide Viewing Angle, True 8-bit, X-ray Image Reproduction |
| Dimensions (WxDxH) | 20.8 in x 1.9 in x 12.8 in - without base |
| Weight | 10.36 lbs |
| Miscellaneous | |
| Features | Security lock slot (cable lock sold separately), robust construction |
| Included Accessories | X-ray film positioner |
| Cables Included | 1 x HDMI cable |
| Compliant Standards | FCC, RoHS, WEEE, DICOM Part 14, REACH, LVD, EAC, IEC/EN 60601-1, IEC/EN 60601-1-2, ICES-003 issue 7 |
| Security Slot Type | Kensington security slot |
| Power | |
| Power Consumption (Typical) | 15 Watt |
| Power Consumption Stand by | 0.5 Watt |
| Power Consumption (Off Mode) | 0.3 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Audio | |
| Type | Speakers - stereo |
| Output Power / Channel | 3 Watt |
| Connectivity | |
| Interfaces | VGA ¦ DisplayPort ¦ HDMI ¦ Audio line-out (mini-jack) ¦ USB 2.0 |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 24 in |
| Shipping Depth | 6.3 in |
| Shipping Height | 15.9 in |
| Shipping Weight | 14.22 lbs |
| Mechanical | |
| VESA Mounting Interface | 100 x 100 mm, 300 x 100 mm |
