Control panel - 8-button - 1 gang - wired - 10/100 Ethernet - white, black
| Main Specifications | |
|---|---|
| Product Description | Atlona Velocity AT-VKP-8E - control panel - 8-button - white, black |
| Product Type | Control panel |
| Gangs Qty | 1 |
| Placing / Mounting | In US type junction box |
| Functions | AV control, room scheduling |
| Power Source | PoE |
| Connectivity | Wired - 10/100 Ethernet |
| Input Type | 8 buttons - keypad |
| Display | 2.7" two-color (monochrome) |
| Color | White, black |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Product Type | Control panel |
| Functions | AV control, room scheduling |
| Gangs Qty | 1 |
| Power Source | PoE |
| Placing / Mounting | In US type junction box |
| Connectivity Technology | Wired - RS-232, Ethernet, Fast Ethernet |
| Display | 2.7" two-color (monochrome) |
| Display Resolution | 264 x 172 pixels |
| Interfaces Details | LAN ¦ Serial (RS-232) |
| Features | Customizable button combinations, RGB LED indicator, PoE, DHCP support, HTTPS support, HTTP support, TCP support, NTP support, IPv4 support, IPv6 support, static IP address support |
| Miscellaneous | |
| Included Accessories | Faceplate (black), faceplate (white) |
| Color | White, black |
| Warranty | 2-year warranty |
| Compliant Standards | FCC, China RoHS, RCM, UKCA, ICES, IEEE 802.3af, IEEE 802.3at |
| Processor | |
| CPU | i.MX6 Cortex-A7 |
| Manufacturer | ARM |
| Clock Speed | 900 MHz |
| RAM | |
| Installed Size | 512 MB |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 10 - 90% RH (non-condensing) |
| Flash Memory | |
| Installed Size | 4 GB |
| Dimensions & Weight | |
| Weight | 5.29 oz |
| Dimensions & Weight Details | With back box: 2.7 in x 1.7 in x 4.5 in ¦ Bezel: 2.7 in x 0.4 in x 4.5 in |
| Control Unit | |
| Input Type | Keypad |
| Buttons Qty | 8 |
