UPS (rack-mountable / external) - Intelligent card slot, lithium-ion, NEMA 5-15R outlets, on-line, tower, with rail kit - AC 120 V - 1800 watt - 2000 VA - 1-phase - RS-232, USB - output connectors: 6 - 2U - black with silver front bezel
| Main Specifications | |
|---|---|
| Product Description | Schneider Electric Easy UPS On-Line SRVSL SRVSL2KRARK - UPS - Intelligent card slot, lithium-ion, NEMA 5-15R outlets, on-line, tower, with rail kit - 1800 watt - 2000 VA |
| Device Type | UPS - rack-mountable / external |
| Rack Size | 2U |
| Weight | 36.6 lbs |
| Input Wiring | 1-phase |
| Input Voltage | AC 120 V |
| Output Voltage | AC 110/115/120 V |
| Power Capacity | 1800 watt / 2000 VA |
| Input Connectors | 1 x power NEMA 5-20P |
| Output connectors | 6 x power NEMA 5-20R - 120 V |
| Battery | Lithium ion |
| Networking | RS-232, USB |
| Included Accessories | Stabilization feet |
| Color | Black with silver front bezel |
| Dimensions (WxDxH) | 17.2 in x 19.8 in x 3.4 in |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | UPS - rack-mountable / external |
| Height (Rack Units) | 2U |
| Color | Black with silver front bezel |
| Expansion / Connectivity | |
| Interfaces | 1 x management (RS-232) ¦ 1 x EPO (emergency power off) ¦ 1 x management (USB) - 4 pin USB Type B |
| Expansion Slots | 1 (total) / 1 (free) x Intelligent Slot |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | Stabilization feet |
| Cables Included | RS-232 cable - external ¦ USB cable - external ¦ Power cable - integrated - 5 ft |
| Rack Mounting Kit | Included |
| Features | Horizontal mounting, vertical mounting, double conversion, 3:1 max crest factor, internal bypass, LCD display |
| Compliant Standards | cTUVus, NOM, RETIE, UN38.3, IP20 |
| Networking | |
| Remote Management Interface | RS-232, USB |
| Software / System Requirements | |
| Software Included | APC PowerChute |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Sound Emission | 50 dBA |
| Battery | |
| Technology | Lithium ion |
| Voltage Provided | 48 V |
| Run Time (Up To) | 10.1 min at 1800 Watts |
| Recharge Time | 2 hours |
| Power Device | |
| UPS Technology | On-line |
| Input Voltage | AC 120 V |
| Input Voltage Range | AC 80 - 150 V |
| Input Voltage Range (Adjustable) | AC 55 - 150 V |
| Frequency Provided | 50/60 Hz ± 3Hz |
| Input Wiring | 1-phase |
| Frequency Required | 40 - 70 Hz |
| Input Connectors | 1 x power NEMA 5-20P |
| Power Output Connectors Details | 6 x power NEMA 5-20R - 120 V |
| Output Voltage | AC 110/115/120 V 50/60 Hz |
| Power Capacity | 1800 watt / 2000 VA |
| Output Waveform | Sinewave |
| Surge Energy Rating | 220 joules |
| Circuit Protection | Circuit breaker |
| Efficiency | 91.3% at 25% Load, 92.4% at 50% Load, 92% at 75% Load, 91.2% at 100% Load |
| Dimensions & Weight | |
| Width | 17.2 in |
| Depth | 19.8 in |
| Height | 3.4 in |
| Weight | 36.6 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 25.6 in |
| Shipping Depth | 22.8 in |
| Shipping Height | 9.4 in |
| Shipping Weight | 50.04 lbs |
