Door contact sensor - enclosure mountable, cabinet mountable - DC 20 - 60 V
| Main Specifications | |
|---|---|
| Product Description | Lantronix EDCA-DIO-01 - door contact sensor |
| Product Type | Door contact sensor |
| Placing / Mounting | Enclosure mountable, cabinet mountable |
| Voltage Required | DC 20 - 60 V |
| Package Content | DIN rail clip |
| Dimensions (WxDxH) | 2 in x 0.9 in x 2 in |
| Weight | 3.17 oz |
| Features | LED status indicators |
| Manufacturer Warranty | Limited lifetime warranty |
| General | |
| Product Type | Door contact sensor |
| Placing / Mounting | Enclosure mountable, cabinet mountable |
| Voltage Required | DC 20 - 60 V |
| Package Content | DIN rail clip |
| Width | 2 in |
| Depth | 0.9 in |
| Height | 2 in |
| Weight | 3.17 oz |
| Manufacturer Warranty | |
| Service & Support | Limited warranty: - lifetime |
| Miscellaneous | |
| MTBF | 9,950,896 hour(s) |
| Features | LED status indicators |
| Compliant Standards | EN 55032, EN55024 |
| Environmental Parameters | |
| Min Operating Temperature | -13 °F |
| Max Operating Temperature | 167 °F |
| Interface Provided | |
| Connector Provided | 6 pin terminal block |
