Adapter cable - 24 pin USB-C male to HDMI male - 3 ft - black/silver - 8K60Hz support, 4K144Hz support, active - for P/N: U415-002-BDS
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series USB-C to HDMI Active Adapter Cable M/M 8K60 Hz 4K 144Hz HDR 4:4:4 HDCP 2.3 Black 3ft - adapter cable - 3 ft |
| Cable | Adapter cable |
| American Wire Gauge (AWG) | 34/24 |
| Max Output Resolution | 7680 x 4320 - 60 Hz |
| Length | 3 ft |
| Color | Black/silver |
| Connector | 24 pin USB-C - male |
| Connector (Second End) | HDMI - male |
| Features | 8K60Hz support, 4K144Hz support, active adapter |
| Manufacturer Warranty | 3-year warranty |
| Designed For | P/N: U415-002-BDS |
| General | |
| Cable Type | Adapter cable 8K60Hz support, 4K144Hz support, active |
| American Wire Gauge (AWG) | 34/24 |
| Jacket Material | Thermoplastic elastomer (TPE) |
| Length | 3 ft |
| Plated Connector | Nickel |
| Features | HDR support, 4:2:0 Chroma Subsampling, 4:2:2 Chroma Subsampling, 4:4:4 Chroma Subsampling, 36-bit deep color, bandwidth of 32.4 Gbps, bus powered, DisplayPort Alternate Mode support, outer diameter 4.2 mm |
| Color | Black/silver |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Compliant Standards | FCC (USA), HDCP 1.4, HDCP 2.3, REACH, RoHS, UKCA |
| Connectivity | |
| Connector | 24 pin USB-C - male |
| Connector (Second End) | 19 pin HDMI Type A - male |
| Dimensions & Weight | |
| Weight | 2.47 oz |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 4.7 in |
| Shipping Depth | 3.9 in |
| Shipping Height | 0.8 in |
| Compatibility Information | |
| Designed For | P/N: U415-002-BDS |
| Adapters & Converters | |
| Max Output Resolution | 7680 x 4320 |
| Refresh Rate | 60 Hz |
