LED monitor - 5MP - color - 21.3" - 2048 x 2560 - IPS - 1100 cd/m² - 1500:1 - 12 ms - DVI-D, DisplayPort - black
| Main Specifications | |
|---|---|
| Product Description | EIZO RadiForce RX560-MD - LED monitor - 5MP - color - 21.3" |
| Device Type | LED-backlit LCD monitor - 5MP - color - 21.3" |
| Number Of Screens | 2 |
| Daisy Chaining | Yes |
| Features | Presence sensor, USB 2.0 hub |
| Sensors | Illuminance sensor |
| Panel Type | IPS |
| Aspect Ratio | 4:5 |
| Native Resolution | 2048 x 2560 |
| Pixel Pitch | 0.165 mm |
| Brightness | 1100 cd/m² |
| Contrast Ratio | 1500:1 |
| Response Time | 12 ms (On/Off) |
| Color Support | 1.074 billion colors (10-bit) |
| Input Connectors | DVI-D, DisplayPort |
| Display Position Adjustments | Height, swivel, tilt, pivot (rotation) |
| Screen Coating | Anti-glare |
| Voltage | (50/60 Hz) |
| Color | Black |
| Dimensions (WxDxH) - with stand | 14 in x 7.9 in x 22.3 in |
| Weight | 38.14 lbs |
| Compliant Standards | FCC Class B certified, DVI DMPM, CCC, RoHS, WEEE, IEC 60601-1, VCCI Class B, CSA C22.2 No. 60601-1, EAC, China RoHS, RCM, ANSI/AAMI ES60601-1, CAN ICES-3 Class B, VDE EN60601-1, DisplayPort 1.2a |
| General | |
| Display Type | LED-backlit LCD monitor / TFT active matrix - 5MP - color |
| Diagonal Size | 21.3" |
| Number Of Screens | 2 |
| Daisy Chaining | Yes |
| Built-in Devices | Presence sensor, USB 2.0 hub |
| Panel Type | IPS |
| Aspect Ratio | 4:5 |
| Native Resolution | 2048 x 2560 |
| Pixel Pitch | 0.165 mm |
| Brightness | 1100 cd/m² |
| Contrast Ratio | 1500:1 |
| Color Support | 1.074 billion colors (10-bit) |
| Response Time | 12 ms (On/Off) |
| Vertical Refresh Rate | 23 - 61 Hz |
| Horizontal Refresh Rate | 31 - 135 kHz |
| Horizontal Viewing Angle | 178 |
| Vertical Viewing Angle | 178 |
| Screen Coating | Anti-glare |
| Backlight Technology | LED backlight |
| OSD Languages | Chinese (traditional), Chinese (simplified), English, German, French, Italian, Swedish, Spanish, Japanese |
| Features | Ambient light sensor, Digital Uniformity Equalizer (DUE), Auto Brightness Stabilization, CAL Switch, Backlight Sensor, Hybrid Gamma, Integrated Front Sensor, presence sensor, frame synchronous mode |
| Color | Black |
| Dimensions (WxDxH) | 14 in x 7.9 in x 22.3 in - with stand |
| Weight | 38.14 lbs |
| Miscellaneous | |
| Cables Included | 2 x DVI cable - DVI-D to DVI-D ¦ 2 x DisplayPort cable - DisplayPort to DisplayPort ¦ 2 x USB cable |
| Compliant Standards | FCC Class B certified, DVI DMPM, CCC, RoHS, WEEE, IEC 60601-1, VCCI Class B, CSA C22.2 No. 60601-1, EAC, China RoHS, RCM, ANSI/AAMI ES60601-1, CAN ICES-3 Class B, VDE EN60601-1, DisplayPort 1.2a |
| Power | |
| Input Voltage | (50/60 Hz) |
| Power Consumption (Typical) | 43 Watt |
| Power Consumption Stand by | 1 Watt |
| Software / System Requirements | |
| Included Software | Screen Manager Pro for Medical, RadiCS LE |
| Connectivity | |
| Interfaces | DisplayPort ¦ DVI-D (dual link) ¦ DisplayPort output ¦ 2 x USB 2.0 downstream ¦ USB 2.0 upstream (Type B) |
| Dimensions & Weight | |
| Dimensions & Weight Details | With stand - width: 14 in - depth: 7.9 in - height: 22.3 in - weight: 38.1 lbs ¦ Without stand - width: 14 in - depth: 3.1 in - height: 17.8 in - weight: 11.7 lbs |
| Mechanical | |
| Display Position Adjustments | Height, swivel, tilt, pivot (rotation) |
| Tilt Angle | -5/+30 |
| Swivel Angle | 70 |
| Rotation Angle | 90 |
| Height Adjustment | 3.5 in |
| VESA Mounting Interface | 100 x 100 mm |
| VR Headset | |
| Sensors | Illuminance sensor |
