Connectorized - wireless access point - Wi-Fi 6 - Bluetooth, Wi-Fi 6E, ZigBee - 2.4 GHz, 5 GHz, 6 GHz - BTO
| Main Specifications | |
|---|---|
| Product Description | HPE Aruba Networking AP-674 (US) - Connectorized - wireless access point - Bluetooth, Wi-Fi 6E, ZigBee |
| Device Type | Wireless access point |
| Form Factor | External - outdoor |
| Localization | United States |
| Data Link Protocol | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.0 LE, ZigBee |
| Frequency Band | 2.4 GHz, 5 GHz, 6 GHz |
| Performance | Maximum data rate (5 GHz): 1.2 Gbps ¦ Maximum data rate (2.4 GHz): 574 Mbps ¦ Maximum data rate (6 GHz): 2.4 Gbps |
| Capacity | Spatial streams: 2 ¦ Associated client devices per radio: 512 ¦ BSSIDs per radio: 16 ¦ OFDMA units: 37 |
| Included Accessories | 30 dBi GPS antenna, external mount |
| OS Required | ArubaOS 10.7.1.0 |
| Power Over Ethernet (PoE) Supported | PoE Class 6 |
| Pricing Type | BTO |
| Dimensions (WxDxH) | 11.4 in x 11.3 in x 8.9 in |
| Weight | 9.26 lbs |
| Manufacturer Warranty | Limited lifetime warranty |
| General | |
| Device Type | Wireless access point |
| Ruggedized Design | Outdoor |
| Width | 11.4 in |
| Depth | 11.3 in |
| Height | 8.9 in |
| Weight | 9.26 lbs |
| Localization | United States |
| Expansion / Connectivity | |
| Interfaces | 1 x 100/1000/2500Base-T - RJ-45 ¦ 1 x 1000Base-SR - SFP+ ¦ 4 x antenna - NF connector ¦ 1 x GPS/GNSS - NF connector ¦ 1 x IoT antenna - NF connector ¦ 1 x console - USB-C ¦ 1 x USB 2.0 (host) - Type C ¦ 1 x USB 2.0 (host) - Type A |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Miscellaneous | |
| Included Accessories | 30 dBi GPS antenna, external mount |
| MTBF | 500,562 hours |
| Compliant Standards | FCC, ISED, RED 2014/53/EU, IEC 62368-1, EN 62368-1, EN 60601-1-1, EN60601-1-2, IP66, IP67, ASTM B117-07A, GR-487 |
| Pricing Type | BTO |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 3.9 Gbps |
| Line Coding Format | CCK, OFDM, BPSK, 16 QAM, 64 QAM, 256 QAM, 1024 QAM, DSSS, QPSK |
| Data Link Protocol | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.0 LE, ZigBee |
| Spread Spectrum Method | OFDMA, DSSS, OFDM |
| Frequency Band | 2.4 GHz, 5 GHz, 6 GHz |
| Performance | Maximum data rate (5 GHz): 1.2 Gbps ¦ Maximum data rate (2.4 GHz): 574 Mbps ¦ Maximum data rate (6 GHz): 2.4 Gbps |
| Capacity | Spatial streams: 2 ¦ Associated client devices per radio: 512 ¦ BSSIDs per radio: 16 ¦ OFDMA units: 37 |
| Status Indicators | System, status, radio |
| Features | Surge protection, Trusted Platform Module (TPM), reset button, Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Advanced Cellular Coexistence (ACC), ClientMatch, packet aggregation A-MPDU, packet aggregation A-MSDU, 160MHz bandwidth support, MU-MIMO technology, Advanced IoT Coexistence (AIC), Zero-touch provisioning (ZTP), Very High Throughput (VHT) support, Target Wait Time (TWT) |
| Encryption Algorithm | WPA3, WPA2-MPSK, WPA3-Enhanced Open |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3bt, IEEE 802.11ax |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE Class 6 |
| Software / System Requirements | |
| OS Required | ArubaOS 10.7.1.0 |
| Environmental Parameters | |
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 149 °F |
| Humidity Range Operating | 5 - 100% (non-condensing internal) |
| Antenna | |
| Antenna | External |
| Internet of Things (IoT) | |
| Internet of Things (IoT) Compatible | Yes |
| Communications Technology | Bluetooth Low Energy (LE), Zigbee |
