Security appliance - 5 ports - 1GbE - Wi-Fi 6 - Bluetooth - 2.4 GHz, 5 GHz - cloud-managed - desktop
| Main Specifications | |
|---|---|
| Product Description | Fortinet FortiWiFi 50G - security appliance - Wi-Fi 6, Bluetooth - cloud-managed |
| Device Type | Security appliance |
| Form Factor | Desktop |
| Localization | Cambodia, Laos, Thailand |
| Processor | 1 x Fortinet FortiASIC SP5 |
| Ports Qty | 5 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, IEEE 802.11ax (Wi-Fi 6), Bluetooth LE |
| Frequency Band | 2.4 GHz, 5 GHz |
| Performance | IPS throughput (enterprise traffic mix): 2.25 Gbps ¦ NGFW throughput (enterprise traffic mix): 1.25 Gbps ¦ Threat protection throughput (enterprise traffic mix): 1.1 Gbps ¦ Firewall throughput (1518-byte UDP): 5 Gbps ¦ Firewall throughput (512-byte UDP): 5 Gbps ¦ Firewall throughput (64-byte UDP): 4 Gbps ¦ Firewall latency (64-byte UDP): 2.42 ?s ¦ Firewall throughput: 6 Mpps ¦ VPN throughput (512-bit IPSec): 4.5 Gbps ¦ SSL inspection throughput: 1.3 Gbps ¦ Application control throughput (HTTP 64K): 2.8 Gbps ¦ CAPWAP throughput: 3.8 Gbps ¦ Maximum data rate (2.4 GHz): 574 Mbps ¦ Maximum data rate (5 GHz): 1201 Mbps |
| Capacity | Concurrent TCP sessions: 720000 ¦ New TCP sessions per second: 85000 ¦ Firewall policies: 2000 ¦ Gateway to gateway IPSec VPN Tunnels: 200 ¦ Client to gateway IPSec VPN tunnels: 250 ¦ SSL inspection CPS: 699 ¦ SSL inspection concurrent sessions: 74000 ¦ Maximum virtual domains: 5 ¦ Virtual domains: 5 ¦ Number of FortiSwitches: 8 ¦ Number of FortiAP devices: 16 ¦ Number of FortiAP devices (tunnel mode): 8 ¦ Number of FortiToken devices: 500 |
| Included Accessories | 3 power plug adapters, 3 x Wi-Fi antennas |
| Power | AC 100-240 V (50/60 Hz) |
| Dimensions (WxDxH) | 8.5 in x 7 in x 1.7 in |
| Weight | 2.43 lbs |
| General | |
| Device Type | Security appliance |
| Width | 8.5 in |
| Depth | 7 in |
| Height | 1.7 in |
| Weight | 2.43 lbs |
| Localization | Cambodia, Laos, Thailand |
| Expansion / Connectivity | |
| Expansion Slots | 2 (total) / 2 (free) x Nano SIM card |
| Interfaces | 1 x USB 3.0 - Type A ¦ 1 x console - RJ-45 ¦ 1 x 1000Base-T - RJ-45 (WAN) ¦ 1 x 1000Base-T (FortiLink) - RJ-45 ¦ 3 x 1000Base-T - RJ-45 ¦ 3 x antenna - SMA |
| Miscellaneous | |
| Included Accessories | 3 power plug adapters, 3 x Wi-Fi antennas |
| Cables Included | 1 x network cable |
| Compliant Standards | FCC, ISED, UL, cUL, CB, USGv6 |
| Networking | |
| Form Factor | Desktop |
| Ports Qty | 5 |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, IEEE 802.11ax (Wi-Fi 6), Bluetooth LE |
| Network / Transport Protocol | DNS, IPSec, HTTP, HTTPs, TCP/IP, IPv6, UDP/IP |
| Remote Management Protocol | HTTP, HTTPS, CLI |
| Cloud-Managed | Yes |
| Frequency Band | 2.4 GHz, 5 GHz |
| Performance | IPS throughput (enterprise traffic mix): 2.25 Gbps ¦ NGFW throughput (enterprise traffic mix): 1.25 Gbps ¦ Threat protection throughput (enterprise traffic mix): 1.1 Gbps ¦ Firewall throughput (1518-byte UDP): 5 Gbps ¦ Firewall throughput (512-byte UDP): 5 Gbps ¦ Firewall throughput (64-byte UDP): 4 Gbps ¦ Firewall latency (64-byte UDP): 2.42 ?s ¦ Firewall throughput: 6 Mpps ¦ VPN throughput (512-bit IPSec): 4.5 Gbps ¦ SSL inspection throughput: 1.3 Gbps ¦ Application control throughput (HTTP 64K): 2.8 Gbps ¦ CAPWAP throughput: 3.8 Gbps ¦ Maximum data rate (2.4 GHz): 574 Mbps ¦ Maximum data rate (5 GHz): 1201 Mbps |
| Capacity | Concurrent TCP sessions: 720000 ¦ New TCP sessions per second: 85000 ¦ Firewall policies: 2000 ¦ Gateway to gateway IPSec VPN Tunnels: 200 ¦ Client to gateway IPSec VPN tunnels: 250 ¦ SSL inspection CPS: 699 ¦ SSL inspection concurrent sessions: 74000 ¦ Maximum virtual domains: 5 ¦ Virtual domains: 5 ¦ Number of FortiSwitches: 8 ¦ Number of FortiAP devices: 16 ¦ Number of FortiAP devices (tunnel mode): 8 ¦ Number of FortiToken devices: 500 |
| Status Indicators | Bluetooth Low Energy (BLE), firmware, power, status, HA, Wi-Fi, link/activity, speed |
| Features | Firewall protection, SD-WAN support, AI powered, self-healing network, Zero Trust Network Access (ZTNA), NGFW appliance, Intrusion Prevention System (IPS), URL filtering, DDoS Protection, Data Loss Prevention (DLP), VPN support, SSL inspection, built-in ASIC, Trusted Platform Module (TPM), High Availability, fanless, 2x2 MIMO technology |
| Encryption Algorithm | SSL, TLS 1.3, 256-bit AES, 256-bit SHA |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax |
| Power | |
| Power Device | External power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Software / System Requirements | |
| OS Provided | FortiOS |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Processor / Memory / Storage | |
| Processors Installed | 1 x Fortinet FortiASIC SP5 |
| Antenna | |
| Antenna | External detachable |
| Antenna Qty | 3 |
| Internet of Things (IoT) | |
| Internet of Things (IoT) Compatible | Yes |
| Communications Technology | Bluetooth Low Energy (LE) |
