Security appliance - 1GbE - Wi-Fi 6, Bluetooth - 2.4 GHz, 5 GHz - wall / ceiling mountable
| Main Specifications | |
|---|---|
| Product Description | Fortinet FortiBranchSASE 10F-WiFi - security appliance - Wi-Fi 6, Bluetooth |
| Device Type | Security appliance |
| Form Factor | Wall / ceiling mountable - indoor |
| Localization | Algeria, Armenia, Bahrain, Brunei, Kuwait, Mongolia, Morocco, Maldives, Nigeria, Senegal, Sri Lanka, Turkmenistan |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), Bluetooth LE |
| Frequency Band | 2.4 GHz, 5 GHz |
| Performance | VPN throughput (IPSec): 900 Mbps ¦ IPsec throughput: 890 Mbps ¦ Lan-Extension throughput: 860 Mbps ¦ LAN-to-WAN NAT 'ed Layer-3 IP packets throughput: 900 Mbps |
| Capacity | Wan uplinks supported: 1 |
| Included Accessories | Wall mounting kit, 4 rubber feet |
| Power Over Ethernet (PoE) Supported | PoE+ |
| Dimensions (WxDxH) | 6 in x 6 in x 2.1 in |
| Weight | 24.69 oz |
| General | |
| Device Type | Security appliance |
| Ruggedized Design | Indoor |
| Width | 6 in |
| Depth | 6 in |
| Height | 2.1 in |
| Weight | 24.69 oz |
| Localization | Algeria, Armenia, Bahrain, Brunei, Kuwait, Mongolia, Morocco, Maldives, Nigeria, Senegal, Sri Lanka, Turkmenistan |
| Expansion / Connectivity | |
| Interfaces | 1 x 10/100/1000Base-T - RJ-45 (WAN) ¦ 1 x 10/100/1000Base-T (PoE+) - RJ-45 ¦ 1 x USB 2.0 - Type A ¦ 1 x console - RJ-45 |
| Miscellaneous | |
| Included Accessories | Wall mounting kit, 4 rubber feet |
| Compliant Standards | EMC 2014/30/EU, EN 300 328, EN 300.440, EN 301 489-1, EN 301 489-7, EN 301 893, EN 50385, EN 55032, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 62311, EN 62368-1, FCC 2.1091, FCC Part 15 B, FCC Part 15 C, FCC Part 15 E, ICES 003, IEC/EN 62368-1, LVD 2014/35/EU, RED 2014/53/EU, RSS-102, RSS-247, UL/CSA 62368-1 |
| Networking | |
| Form Factor | Wall / ceiling mountable |
| Connectivity Technology | Wired, wireless |
| Data Transfer Rate | 1.8 Gbps |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), Bluetooth LE |
| Frequency Band | 2.4 GHz, 5 GHz |
| Performance | VPN throughput (IPSec): 900 Mbps ¦ IPsec throughput: 890 Mbps ¦ Lan-Extension throughput: 860 Mbps ¦ LAN-to-WAN NAT 'ed Layer-3 IP packets throughput: 900 Mbps |
| Capacity | Wan uplinks supported: 1 |
| Status Indicators | Power, LAN, WAN, Wi-Fi, Bluetooth Low Energy (BLE) |
| Features | 2x2 MIMO technology, CAPWAP support, network diagnostics, remote VPN tunnel mode, Layer 2 Control Protocol tunneling, Split Tunneling, Zero-touch provisioning (ZTP), command-line interface (CLI) management, security slot (Kensington security lock compatible) |
| Compliant Standards | IEEE 802.3af, IEEE 802.3at |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE+ |
| Power Device | External power adapter / power injector (not included) |
| Power Consumption Operational | 11 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 5 - 95% RH |
| Antenna | |
| Antenna | Internal |
| Antenna Qty | 2 |
