Speaker - for PA system - 10 Watt - dual cone - off-white
| Main Specifications | |
|---|---|
| Product Description | Speco G86TG1X1 - speaker - for PA system |
| Product Type | Speaker - for PA system |
| Speaker Type | Dual cone passive |
| Continuous Power | 10 watt |
| Peak Power | 15 watt |
| Frequency Response | 85 - 20000 Hz |
| Nominal Impedance | 8 ohm |
| Integrated Transformer | 25V/70V operation or 8 Ohm operation |
| Color | Off-white |
| Dimensions (WxDxH) | 1 in x 3.5 in x 1 in |
| General | |
| Product Type | Speaker - for PA system |
| Enclosure Color | Off-white |
| Enclosure Material | Steel grille |
| Miscellaneous | |
| Compliant Standards | NDAA |
| Dimensions & Weight | |
| Width | 1 in |
| Depth | 3.5 in |
| Height | 1 in |
| Speaker System | |
| Speaker Type | Dual cone passive |
| Continuous Power | 10 watt |
| Continuous Power Details | RMS |
| Peak Power | 15 watt |
| Frequency Response | 85 - 20000 Hz |
| Nominal Impedance | 8 ohm |
| Max Output Level (Max SPL) | 100 dB |
| Sensitivity | 90 dB (1W@1m) |
| Magnet Type | Ferrite |
| Integrated Transformer | 25V/70V operation or 8 Ohm operation |
| Coverage | 120° conical |
| Recommended Placing | In-ceiling mounted |
| Speaker System Details | |
| Driver Details | Speaker: woofer driver - 8" - paper - cone ¦ Speaker: tweeter driver - 0.8" - Dual Cone |
| Cutout & Mounting Dimensions | |
| Diameter | 11.3 in |
