Switch - L3 - managed - 24 x 10/100/1000 - front to back airflow - plug-in module - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | HPE Aruba Networking CX 5420 24p 10M/100M/1G TAA Module - switch - 24 ports - managed - plug-in module - TAA Compliant |
| Device Type | Switch - 24 ports - L3 - managed |
| Enclosure Type | Front to back airflow plug-in module 1U |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 |
| Performance | Forwarding capacity: 160 Gbps |
| Capacity | Latency: 2.5 ?s ¦ Packet buffer memory: 64 MB |
| Routing Protocol | IGMP, OSPF, VRRP, IGMPv3, MLDv2, ECMP, static IP routing, static IPv6 routing, RSTP, MSTP, STP |
| Remote Management Protocol | RMON, SNMP 2c, SNMP 3, TFTP, SFTP, SSH, CLI, NTP |
| Features | QoS, layer 2 switching, layer 3 routing, VRRP support, UDLD, LACP, ToS, EQS, REST API interface, sFlow, Rapid PVST+, MVRP, BPDU |
| Compliant Standards | IEEE 802.1s, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.1w, IEEE 802.1p, IEEE 802.1ab (LLDP), IEEE 802.1Q, IEEE 802.1v, IEEE 802.1ak, IEEE 802.1AX, IEEE 802.1t, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3z |
| Dimensions (WxDxH) | 8.4 in x 9 in x 1.7 in |
| Weight | 32.48 oz |
| TAA Compliant | Yes |
| Manufacturer Warranty | Limited lifetime warranty |
| General | |
| Device Type | Switch - 24 ports - L3 - managed |
| Enclosure Type | Front to back airflow plug-in module 1U |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 |
| Performance | Forwarding capacity: 160 Gbps |
| Capacity | Latency: 2.5 ?s ¦ Packet buffer memory: 64 MB |
| Routing Protocol | IGMP, OSPF, VRRP, IGMPv3, MLDv2, ECMP, static IP routing, static IPv6 routing, RSTP, MSTP, STP |
| Remote Management Protocol | RMON, SNMP 2c, SNMP 3, TFTP, SFTP, SSH, CLI, NTP |
| Authentication Method | Secure Shell (SSH), RADIUS, TACACS+ |
| Features | QoS, layer 2 switching, layer 3 routing, VRRP support, UDLD, LACP, ToS, EQS, REST API interface, sFlow, Rapid PVST+, MVRP, BPDU |
| Compliant Standards | IEEE 802.1s, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.1w, IEEE 802.1p, IEEE 802.1ab (LLDP), IEEE 802.1Q, IEEE 802.1v, IEEE 802.1ak, IEEE 802.1AX, IEEE 802.1t, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3z |
| Expansion / Connectivity | |
| Interfaces | 24 x 10/100/1000 Base-T RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Miscellaneous | |
| Compliant Standards | IEC 62368-1: 2014 Second Edition, IEC 62368-1:2018 Third Edition, IEC 60825-1:2014, EN 60825-1:2014 + A11:2021, Laser Class 1, EN 62368-1:2014+A11:2017 2nd Ed., EN IEC 62368-1:2020+A11:2020 Third Edition, UL 62368-1 Third Edition, CAN/CSA C22.2 No. 62368-1-19, CNS 15598-1:2020, EN 55032:2015+A11:2020 Class A, CISPR 32:2015+AMD1:2019 Class A, FCC Part 15 B Class A, VCCI, Directive 2014/35/EU, CISPR 35: 2016, EN 55035:2017+A11:2020, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, EN IEC 61000-3-2, IEC/EN 61000-3-3 |
| TAA Compliant | Yes |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 5 - 95% RH (non-condensing) |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 158 °F |
| Humidity Range Storage | 5 - 95% RH (non-condensing) |
| Dimensions & Weight | |
| Width | 8.4 in |
| Depth | 9 in |
| Height | 1.7 in |
| Weight | 32.48 oz |
