Network Advantage - switch - L3 - managed - 24 x 10/100/1000 (UPOE) + 4 x 25 Gigabit SFP (uplink) - rack-mountable - UPOE - federal government
| Main Specifications | |
|---|---|
| Product Description | Cisco Catalyst 9300L Mini - Network Advantage - switch - 24 ports - managed - rack-mountable |
| Device Type | Switch - 24 ports - L3 - managed - stackable |
| Enclosure Type | Rack-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 (UPOE) + 4 x 25 Gigabit SFP (uplink) |
| Power Over Ethernet (PoE) | UPOE |
| Performance | Stacking bandwidth: 320 Gbps ¦ Switching capacity: 248 Gbps ¦ Switching capacity with stacking: 568 Gbps ¦ Forwarding rate: 184.51 Mpps ¦ Forwarding rate with stacking: 422.59 Mpps |
| Capacity | IPv4 routes: 32000 ¦ IPv6 routes: 16000 ¦ Multicast scale: 8000 ¦ QoS scale entries: 5120 ¦ ACL scale entries: 5120 ¦ Buffer capacity (MB): 16 ¦ FNF entries: 64000 ¦ VLAN IDs: 4094 ¦ Switched virtual interfaces (SVIs): 1000 ¦ Routed ports: 416 ¦ OSPF routes: 1000 |
| MAC Address Table Size | 32000 entries |
| Jumbo Frame Support | 9198 bytes |
| Routing Protocol | RIP-1, RIP-2, EIGRP, OSPF, policy-based routing (PBR), PIM-SM, VRRP, OSPFv3, PIM-SSM, RIPng, MSTP |
| Remote Management Protocol | NETCONF, RESTCONF, YANG, gRPC, IPv4, IPv6, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3, CLI |
| Features | Cisco StackWise Technology, hot swappable 3 fans, Cisco StackWise-320 technology, SDN, Preboot Execution Environment, ZTP, PVLAN support, CDP, QoS, FHS, MACsec, CoPP, Cisco IP SLA, NetFlow, SPAN, RSPAN, ACL support, Rapid PVST+, SRR, EEE, CoS, FNF, DSCP support, Blue Beacon LED, secure boot, PIM, CIR, Cisco Trust Anchor module, Cisco UADP 2.0, built-in ASIC |
| Compliant Standards | IEEE 802.1ae, IEEE 802.1x, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 1588v2, IEEE 802.1BA, IEEE 802.3bt, Wi-Fi CERTIFIED 6 |
| Power | AC 100-240 V (50 - 60 Hz) |
| Power Redundancy | Optional |
| Dimensions (WxDxH) | 17.5 in x 13.1 in x 1.7 in |
| Weight | 11.49 lbs |
| Pricing Type | Federal government |
| Manufacturer Warranty | Limited lifetime warranty |
| General | |
| Device Type | Switch - 24 ports - L3 - managed - stackable |
| Enclosure Type | Rack-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 (UPOE) + 4 x 25 Gigabit SFP (uplink) |
| Power Over Ethernet (PoE) | UPOE |
| Performance | Stacking bandwidth: 320 Gbps ¦ Switching capacity: 248 Gbps ¦ Switching capacity with stacking: 568 Gbps ¦ Forwarding rate: 184.51 Mpps ¦ Forwarding rate with stacking: 422.59 Mpps |
| Capacity | IPv4 routes: 32000 ¦ IPv6 routes: 16000 ¦ Multicast scale: 8000 ¦ QoS scale entries: 5120 ¦ ACL scale entries: 5120 ¦ Buffer capacity (MB): 16 ¦ FNF entries: 64000 ¦ VLAN IDs: 4094 ¦ Switched virtual interfaces (SVIs): 1000 ¦ Routed ports: 416 ¦ OSPF routes: 1000 |
| MAC Address Table Size | 32000 entries |
| Jumbo Frame Support | 9198 bytes |
| Max Units In A Stack | 8 |
| Routing Protocol | RIP-1, RIP-2, EIGRP, OSPF, policy-based routing (PBR), PIM-SM, VRRP, OSPFv3, PIM-SSM, RIPng, MSTP |
| Remote Management Protocol | NETCONF, RESTCONF, YANG, gRPC, IPv4, IPv6, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3, CLI |
| Encryption Algorithm | 128-bit AES, 256-bit AES |
| Features | Cisco StackWise Technology, hot swappable 3 fans, Cisco StackWise-320 technology, SDN, Preboot Execution Environment, ZTP, PVLAN support, CDP, QoS, FHS, MACsec, CoPP, Cisco IP SLA, NetFlow, SPAN, RSPAN, ACL support, Rapid PVST+, SRR, EEE, CoS, FNF, DSCP support, Blue Beacon LED, secure boot, PIM, CIR, Cisco Trust Anchor module, Cisco UADP 2.0, built-in ASIC |
| Compliant Standards | IEEE 802.1ae, IEEE 802.1x, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 1588v2, IEEE 802.1BA, IEEE 802.3bt, Wi-Fi CERTIFIED 6 |
| RAM | 8 GB |
| Flash Memory | 16 GB |
| Status Indicators | Status |
| Expansion / Connectivity | |
| Interfaces | 24 x 1000Base-T RJ-45 UPOE - 60 W ¦ 4 x 25GBase-X SFP uplink ¦ Network stack device ¦ 1 x management (LAN) RJ-45 ¦ 1 x console ¦ 1 x USB 2.0 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - replacement - lifetime - response time: next business day ¦ Technical support - consulting - 90 days |
| Miscellaneous | |
| MTBF | 357,350 hours |
| Compliant Standards | Plug and Play, ETA, AN/NZS 60950.1, CAN/CSA C22.2 No. 60950-1, CISPR 32 Class A, CISPR 35, CNS 13438, EN 300 386, EN 300 386 V1.6.1, EN 55032 Class A, EN 55035, EN 60950-1, EN 61000-3-2, EN 61000-3-3, FCC CFR47 Part 15, ICES-003 Class A, IEC 60950-1, KN32, KN35, QCVN 118:2018, RoHS, TCVN 7189 Class A, TCVN 7317, UL 60950-1, V-2/2015.04, V-3 Class A, V-3/2015.04, VCCI-CISPR 32:2016 Class A, WEEE |
| Pricing Type | Federal government |
| Power | |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Power Redundancy | Optional |
| Power Provided | 600 Watt |
| Voltage Required | AC 100-240 V (50 - 60 Hz) |
| Software / System Requirements | |
| Software Included | Cisco IOS XE 17.9 Universal |
| Environmental Parameters | |
| Min Operating Temperature | 23 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 158 °F |
| Humidity Range Storage | 5 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 17.5 in |
| Depth | 13.1 in |
| Height | 1.7 in |
| Weight | 11.49 lbs |
