USFF - Celeron J3355 / up to 2.5 GHz - RAM 4 GB - SSD - eMMC 64 GB - HD Graphics 500 - Gigabit Ethernet - no OS - monitor: none - black
| Main Specifications | |
|---|---|
| Product Description | Shuttle Edge series EN01J3 - USFF - AI Ready - Celeron J3355 2 GHz - 4 GB - SSD 64 GB |
| Type | Personal computer - USFF AI Ready |
| Processor | Intel Celeron J3355 / 2 GHz (, up to 2.5 GHz, (Dual-Core) |
| Cache Memory | 2 MB |
| Cache Per Processor | 2 MB |
| RAM | 4 GB LPDDR4 SDRAM |
| Storage Controller | SATA (SATA 6Gb/s) |
| Hard Drive | SSD 64 GB - eMMC |
| Optical Storage | No optical drive |
| Card Reader | Yes |
| Graphics Controller | Intel HD Graphics 500 |
| Networking | 1GbE |
| OS Provided | No operating system |
| Software Included | Drivers & Utilities |
| Color | Black |
| Dimensions (WxDxH) | 3.6 in x 2.1 in x 3.5 in |
| Weight | 16.93 oz |
| General | |
| Type | Personal computer - AI Ready |
| Product Form Factor | USFF |
| Color | Black |
| Expansion / Connectivity | |
| Slots | 1 (total) / 1 (free) x M.2 Card - 3042 (Key B) |
| Interfaces | 2 x USB 3.2 Gen 1 ¦ 1 x USB 2.0 - micro-USB ¦ 1 x HDMI ¦ 1 x LAN (Gigabit Ethernet) |
| Miscellaneous | |
| Included Accessories | VESA mounting kit, screw set, DIN-rail bracket |
| Cables Included | DC input cable |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| VESA Mounting Interface | 100 x 100 mm, 75 x 75 mm |
| Compliant Standards | VCCI, BSMI, CB, FCC, RoHS, ETL, ERP, IP20, EMI, RCM, ErP 2009/125/EC, EMC 2014/30/EU, LVD 2014/35/EU, RED 2014/53/EU |
| RAM | |
| Installed Size | 4 GB |
| Technology | LPDDR4 SDRAM |
| Effective Memory Speed | 2400 MHz |
| Configuration Features | Provided memory is soldered |
| Networking | |
| Ethernet Controller | Realtek RTL8119I-CG |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Features | Wake on LAN (WoL) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Storage Controller | |
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| Cache Memory | |
| Installed Size | 2 MB |
| Cache Per Processor | 2 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel HD Graphics 500 |
| Operating System / Software | |
| OS Provided | No operating system |
| Software | Drivers & Utilities |
| Hard Drive | |
| Type | SSD - eMMC |
| Capacity | 1 x 64 GB |
| Dimensions & Weight | |
| Width | 3.6 in |
| Depth | 2.1 in |
| Height | 3.5 in |
| Weight | 16.93 oz |
| Card Reader | |
| Type | Card reader |
| Supported Flash Memory Cards | microSD, microSDHC, microSDXC |
| Processor / Chipset | |
| CPU | Intel Celeron J3355 |
| Clock Speed | 2 GHz |
| Max Turbo Speed | 2.5 GHz |
| Number of Cores | Dual-Core |
| CPU Qty | 1 |
